Артикул
Название
Примечание
Количество
1
1502272C1
HUB CARRIER
HUB, carrier
2шт.
2
934654R1
BOLT,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd
SCREW, M12 x 25
24шт.
3
3216594R1
OIL SEAL
SEAL, oil
2шт.
4
3216593R1
WASHER
WASHER
2шт.
5
3230271R1
BEARING
inner
2шт.
6
3230280R1
HUB
wheel
2шт.
7
3230876R1
BOLT,Wheel, Serr, M18 x 1.5 x 61 mm
wheel
16шт.
8
712824R1
LOCK WASHER,M18.5, Spring
WASHER, lock
16шт.
9
933800R1
NUT
wheel
16шт.
10
533727R1
BEARING, CUP
2шт.
10
533726R91
BEARING
cone
2шт.
11
3146675R1
RING, SNAP
2шт.
12
3230266R1
RING CARRIER
CARRIER, ring gear 72T
2шт.
13
3230267R1
GEAR, RING
72T
2шт.
14
3230269R1
NUT
adj
2шт.
15
3230270R1
DISC
RING, locking
2шт.
16
3230269R1
NUT
adj
2шт.
17
(Not used this application)
1шт.
18
3230265R1
GEAR
sun 18T
2шт.
19
933074R1
SNAP RING,M28, Ext
RING, retaining
2шт.
20
3147209R2
PLUG
thrust
2шт.
21
3147212R1
WASHER
SHIM, .3mm
2шт.
21
3147211R1
WASHER
SHIM, .5mm
2шт.
21
3147210R1
SHIM
1.0mm
2шт.
22
3230259R1
PINION CARRIER
CARRIER, planetary
2шт.
23
930294R1
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
SCREW, M8 x 30
54шт.
932840R1
LOCK PIN,M8 x 26, Slotted
PIN, 8 x 26 coiled spring
8шт.
932742R1
LOCK PIN,M5 x 26, Slotted
PIN, 5 x 26 slt-spr
8шт.
24
717072R1
SNAP RING,M22, Ext
RING, retaining 24 x 1.2
6шт.
25
3230260R1
SHAFT
planet gear
1шт.
26
933255R1
CIRCLIP,Ext, M20.2
RING, snap
6шт.
27
933709R1
PACKING RING
RING, seal
2шт.
28
934651R1
PLUG,Hex Soc, M18 x 1.5
Control Hex Soc, M18 x 1.5
2шт.
28
933718R1
PLUG,Hex, M24 x 1.5
Drain Hex, M24 x 1.5
2шт.
29
3146668R1
THRUST WASHER
12шт.
30
3146667R1
WASHER
12шт.
31
3230262R1
NEEDLE BEARING
BEARING, needle
32шт.
32
3230261R1
GEAR
planet 26T
6шт.
33
933565R1
PLUG,M14, Conical
cup
2шт.
Выбрано товаров: 39
