Артикул
Название
Примечание
Количество
1
529874R1
SUPPORT
BRACKET, CHECK CHAIN L.H.
1шт.
413-1032
BOLT,Hex, 5/8" - 11 x 2", Gr 5
5/8-11 X 2 HEX HD CAP
1шт.
103325
LOCK WASHER,5/8"
1шт.
2
538406R1
COTTER PIN
PIN, QA COTTER
2шт.
3
3118060R1
PIN
LOWER LINK
2шт.
4
3121157R91
LOWER LINK
ASSY, FRONT SECTION LH
1шт.
32-2024
COTTER PIN,5/16" x 1 1/2"
1шт.
5
3118063R1
PIN
LOWER LINK DRAWBAR
2шт.
6
403019R1
LOWER LINK
ASSY, REAR SECTION LH
1шт.
7
662632R1
SPRING
CHECK CHAIN RESTRAINING
2шт.
8
3121228R1
BRACKET
SWAY CHAIN
2шт.
271554
GREASE,Hex, 5/8" - 11 x 1", Gr 5
5/8-11 X 1 HEX HD CAP
4шт.
9
533189R1
PIN
ASSY, LOWER LINK DRAWBAR
2шт.
10
403020R1
LOWER LINK
ASSY, REAR SECTION RH
1шт.
11
3121158R91
LOWER LINK
ASSY, FRONT SECTION RH
1шт.
32-2024
COTTER PIN,5/16" x 1 1/2"
1шт.
12
403023R1
LATCH
REAR SECTION LOWER
2шт.
13
403024R1
SPRING
2шт.
14
19853R1
LOCK NUT,7/8"-14
7/8-14 HEX
2шт.
15
NOT USED
1шт.
16
527985R1
EYEBOLT,Eye, 7/8" - 14 x 1.90"
BOLT, EYE
2шт.
17
528112R2
PIN,15.77mm OD x 54.61mm L
LIMITER CHAIN
2шт.
118630
PIN
1/8 X 7/8 COTTER
2шт.
18
3118016R1
CLEVIS,7/8" - 14
LIMITER CHAIN LH THD
2шт.
19
3116619R1
NUT
ADJUSTMENT
2шт.
20
219754
BACK-UP RING
7/8-14 HEX JAM
2шт.
21
70622C1
CLEVIS,7/8" - 14
LIMITER CHAIN
2шт.
22
403037R2
PIN
LIMITER CHAIN
2шт.
108630
COTTER PIN,1/8" x 7/8"
2шт.
23
3113595R1
CHAIN,139.7mm L
LIMITER
2шт.
24
528112R2
PIN,15.77mm OD x 54.61mm L
LIMITER CHAIN
4шт.
108630
COTTER PIN,1/8" x 7/8"
2шт.
108630
COTTER PIN,1/8" x 7/8"
2шт.
25
3113594R1
PLATE
STRAP, CHECK CHAIN ADJ
4шт.
26
529875R1
SUPPORT
BRACKET, CHECK CHAIN RH
1шт.
413-1036
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
SCREW, 5/8-11 X 2 HEX HD CAP
2шт.
103325
LOCK WASHER,5/8"
2шт.
27
720631R1
LINCH PIN
ADJ STRAP COTTER
2шт.
28
591261R1
PIN,3/8" x 2 1/8", Coiled
2шт.
29
19903R1
PIN,1/2" x 1 3/4", Coiled
2шт.
1092798R2
PRODUCT GRAPHIC
SWAY CHAINS, AGRICULTURAL MACHINES, NOT ILLUSTRATED
1шт.
1093311R1
DECAL
SWAY CHAINS, INDUSTRIAL MACHINES, NOT ILLUSTRATED
1шт.
Выбрано товаров: 42
