Запчасти Case IH 744 (2F013) - WEIGHTS (07) - HYDRAULICS

NSS

NOT SOLD SEPARAT

WEIGHTS for rear wheels

1шт.

21606R1

BOLT, 5/8" x 254 mm

1шт.

21283R1

BOLT,5/8" x 8", Gr 1

5/8" x 203 mm

1шт.

20874R1

CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 6 1/2", Gr 2

1шт.

22013R1

BOLT

5/8" x 133 mm

1шт.

22013R1

BOLT

5/8" x 120 mm

1шт.

21776R1

CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 3 1/4", Gr 2

1шт.

411-1044

CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 3/4", Gr 2

1шт.

92-11062

LOCK WASHER,5/8"

1шт.

425-1010

NUT,5/8"-11, G5

1шт.

NSS

NOT SOLD SEPARAT

WEIGHTS front

1шт.

413-1072

BOLT,Hex, 5/8" - 11 x 4-1/2", Gr 5

1шт.

413-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5

1шт.

413-1024

BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5

1шт.

495-81027

WASHER,21/32" x 1 1/2" x .120"

1шт.

3141928R2

LARGE PLATE

PLATE, LARGE BAR, 140 x 125 x 10 mm

1шт.

1

3147824R1

WEIGHT

front, with draw clevis

1шт.

2

3147825R92

PIN,32mm OD x 508.85mm L

with chain and spring clip

1шт.

3

1328360C1

SPRING CLIP

SPRING clip

1шт.

4

3147462R92

PIPE

1шт.

5

3059418R1

CHAIN,Knotted link, 39 pitch x .20m

1шт.
