Артикул
Название
Примечание
Количество
1
A60020
SPARE PART
HOUSING - axle (Replaces A34655)
2шт.
3
A33050
OIL SEAL
- housing (9 x 9-1/4 x 1/8")
2шт.
4
A28134
BEARING CUP
CUP - bearing (5-1/4" O.D.)
4шт.
5
40442
ROLLER BEARING,3.25" ID x 1.172"
CONE - bearing (3-1/4" I.D.)
4шт.
6
A41814
SEAL
- oil (3-1/2 x 5-1/4 x 7/16")
2шт.
7
A57909
SHAFT
- axle, w/out collar & w/38 spline teeth, see figure 156
2шт.
8
A57910
GEAR - drive (3-5/16" I.D. w/38 internal teeth)
2шт.
9
A57911
WASHER
- thrust (3-9/32 x 4-1/4 x 7/16")
2шт.
10
A32806
LOCK WASHER
- lock, drive gear
2шт.
11
A23386
NUT
- drive gear retaining
2шт.
12
A34890
BUCKET TOOTH KEY
KEY - axle (6" long) (.625 x .625 sq.)
2шт.
18
A34655
HOUSING AXLE - (1st used trac. ser. no. 8292763) (Order A60020), 3" axle, Serial Range: 48"-88"
2шт.
19
BOLT (SPREADER)
BOLT - housing (5/8 x 2-1/4" N.C. hex.), 3" axle, Serial Range: 48"-88"
16шт.
20
A33050
OIL SEAL
- housing (9 x 9-1/4 x 1/8"), 3" axle, Serial Range: 48"-88"
2шт.
21
A28134
BEARING CUP
CUP - bearing (5-1/4" O.D.), 3" axle, Serial Range: 48"-88"
4шт.
22
A28135
ROLLER BEARING,3.0625" ID x 1.172"
CONE - bearing (3" I.D.), 3" axle, 48" to 88"
4шт.
23
A34656
OIL SEAL
- oil (3-3/4 x 5-1/4 x 7/16") (used w/A34655 housing), 3" axle, Serial Range: 48"-88"
2шт.
24
A33046
SHAFT - axle, w/collar & w/33 spline teeth and length of 30 11/32 ", 3" axle, Serial Range: 48"-88"
2шт.
25
NLS
NO LONGER SERVICED
- drive (2-7/8" I.D. w/33 internal teeth), 3" axle, Serial Range: 48"-88"
2шт.
26
A33048
WASHER - thrust (3-3/32 x 4-1/4 x 7/16"), 3" axle, Serial Range: 48"-88"
2шт.
27
A32806
LOCK WASHER
- lock, drive gear, 3" axle, Serial Range: 48"-88"
2шт.
28
A23386
NUT
- drive gear retaining, 3" axle, Serial Range: 48"-88"
2шт.
29
A22917
KEY
- axle (4" long) (1/2 x 3/4"), 3" axle, Serial Range: 48"-88"
2шт.
30
A29426
AXLE PIN
PIN - key to axle (3/8 x 3/4"), 3" axle, Serial Range: 48"-88"
2шт.
31
A23385
NUT
- axle, 3" axle, Serial Range: 48"-88"
2шт.
32
132-157
COTTER PIN,Ext Prong Sq Cut, 1/4" x 2 1/2"
Pin, Split (Cotter), , Nut, 3" axle, 48" to 88" 1/4" x 2 1/2"
2шт.
35
X
HOUSING - axle (used prior to trac. ser. no. 8292763) (Order 1-A60020 Hsg. & 1-A34656 Oil Seal), 3" axle, Serial Range: 48"-88"
2шт.
36
A28138
OIL SEAL
SEAL - oil (3-3/4 x 4-3/4 x 15/16") (used w/A26340 housing), 3" axle, Serial Range: 48"-88"
2шт.
37
A28139
GUARD
- dust (used w/A26340 housing), 3" axle, Serial Range: 48"-88"
2шт.
38
A28140
GASKET
- dust guard, 3" axle, Serial Range: 48"-88"
2шт.
39
13-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
Guard, 3" axle, 48" to 88" Hex, 5/16"-18 x 3/4", G5, Full Thd
12шт.
40
92-5
LOCK WASHER,5/16"
3" axle, 48" to 88" 5/16"
12шт.
Выбрано товаров: 34
