Артикул
Название
Примечание
Количество
1
378502R22
AXLE
ASSEMBLY - front, Includes: Ref. 2 and 3
1шт.
2
378813R1
BUSHING
- front axle
2шт.
3
530975R2
SPACER
- front axle
1шт.
4
109461
LUBE NIPPLE,1/8"-27 x .66 lg
NIPPLE, LUBE, , PT 1/8"-27 x .66 lg
3шт.
5
85999C1
PIN
- front axle pivot
1шт.
6
413-860
BOLT,Hex, 1/2" - 13 x 3-3/4", Gr 5
1шт.
7
425-108
NUT,1/2" - 13, Gr 5
NUT, , Hex 1/2"-13, G5
1шт.
8
61554R1
WASHER
SHIM - steering knuckle, light
1шт.
8
70586R1
SHIM
- steering knuckle, medium
1шт.
9
21076D
BEARING ASSY,31.9mm ID x 55.56mm OD x 16.13mm W
BEARING - thrust, steering knuckle
2шт.
10
70594R91
KIT
PIN - king, pivot
2шт.
11
62798H
KEY
- king pin
2шт.
12
492-11038
LOCK WASHER,3/8"
2шт.
13
425-146
JAM NUT,3/8" - 16, Gr 5
- hex jam, 3/8 inch NC
2шт.
14
112775R11
STEERING KNUCKLE
KNUCKLE ASSEMBLY - steering, Includes: Ref. 15
2шт.
14
1213434C91
KNUCKLE
ASSEMBLY - steering (Optional to 112775R11), Includes: Ref. 15
2шт.
15
70589R1
BRONZE BUSHING,31.37mm ID x 34.66mm OD x 40.21mm L
BUSHING - steering knuckle
2шт.
16
107317
GROOVED PIN,3/16" x 1/2", Type A
Pin, Grooved, 3/16" x 1/2", Type A
2шт.
17
273348
LUBE NIPPLE
FITTING - grease, short, 1/8 inch PT
2шт.
19
70590R1
CAP
- steering knuckle
4шт.
20
392-11031
LOCK WASHER,5/16"
5/16"
8шт.
21
51124V
SCREW
- steering knuckle cap
8шт.
22
378399R1
ARM
- steering knuckle, left
1шт.
23
378400R1
ARM
- steering knuckle, right
1шт.
24
414-1060
BOLT,Hex, 5/8" - 18 x 3-3/4", Gr 5
- hex, 5/8 NF x 3-3/4 inch
4шт.
25
414-1036
BOLT,Hex, 5/8" - 18 x 2-1/4", Gr 5
- hex, 5/8 NF x 2-1/4 inch
2шт.
26
425-1110
NUT,5/8"-18, G5
6шт.
NSS
NOT SOLD SEPARAT
ROD ASSEMBLY - tie, Includes: Ref. 28 - 32
1шт.
28
70689C1
TUBE,1.188" OD, 37.72" Length
- connecting
1шт.
29
379327R91
END
ASSEMBLY - rod, right
1шт.
30
379329R1
LOCK NUT
- lock, right
1шт.
31
379326R91
END
ASSEMBLY - rod, left
1шт.
32
379328R1
LOCK NUT
- lock, left
1шт.
33
1332991C1
SEAL
- tie rod end
2шт.
34
425-1910
SLOTTED NUT,5/8"-18, G5, Thk
NUT - hex slotted, 5/8 inch NF
2шт.
35
32-822
COTTER PIN,1/8" x 1 3/8"
Pin, Split (Cotter), 1/8" x 1 3/8"
2шт.
36
1970726C1
SEAL
- steering cylinder ball joint
1шт.
37
518505R1
HEADED PIN,3/4" x 3"
PIN - headed, 3/4 x 3 inch
1шт.
Выбрано товаров: 39
