Запчасти Case IH 685 (4-168) - CABLE HARNESS AND CONNECTIONS (04) - ELECTRICAL SYSTEMS

1500966C96

HARNESS

ASSY., main cable

1шт.

3115813R1

FUSE

35 amp

6шт.

3121403R1

FUSE

35 amp

6шт.

3118918R1

FUSE

10 amp

4шт.

3118918R1

FUSE

5 amp

4шт.

3123157R1

COVER

2шт.

3123158R1

PACKAGE

alternator socket

1шт.

3129948R1

BOX, FUSE

PACKAGE fuse box

1шт.

3125877R1

HARNESS

cab lighting

1шт.

528301R1

CABLE ASSY.

battery starting motor

1шт.

3123190R2

CABLE ASSY.

cab mounting, earth lead

1шт.

705896R1

CONNECTOR, ELEC

CONNECTOR tachometer

1шт.

705897R1

CONNECTOR, ELEC

CONNECTOR speedometer

1шт.

289862C1

CABLE TIE,3/16" x 7"

CABLE STRAP Steering support, left, top

1шт.

306132C1

CABLE TIE,14.5" L

CABLE STRAP harness to instrument shroud

2шт.

3116240R1

CLIP

battery cable

1шт.

450643

SCREW,Hex Hd, #8-32 x 3/8"

BOLT

1шт.

225-10108

NUT,#8-32

1шт.

492-11008

LOCK WASHER,#8

1шт.

3123109R1

CABLE CLIP

temperature sender

1шт.

100770H

CLIP

grille shroud

1шт.

3113490R1

CLIP

steering support

1шт.

289862C1

CABLE TIE,3/16" x 7"

CABLE STRAP Harness to battery support

1шт.

316433C1

CLAMP

CLIP cable, main harness

1шт.

179812

GEAR

5/16 x 2-1/2

1шт.

103320

LOCK WASHER,5/16"

1шт.

316433C1

CLAMP

CLIP cable

1шт.

179833

BOLT,Hex, 3/8" - 16 x 1/2", Gr 5, Full Thd

1шт.

103321

LOCK WASHER,3/8"

1шт.

289862C1

CABLE TIE,3/16" x 7"

CABLE STRAP Safety start cable to battery tray

1шт.

3113490R1

CLIP

harness to master cylinder bracket

1шт.

366460R1

CABLE CLIP

front cover, right rear

1шт.

306132C1

CABLE TIE,14.5" L

CABLE STRAP steering support, right, top

1шт.

100770H

CLIP

injection pump cover

2шт.

1500496C1

CABLE CLIP

cab, rear frame

3шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

3шт.

1502019C1

SCREW,Hex Random Sl, #10 - 24 x 1/2"

optional

3шт.

3123195R1

CLAMP

CLIP

3шт.

1502353C1

CABLE CLIP

cab frame, left, top

3шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

3шт.

1502019C1

SCREW,Hex Random Sl, #10 - 24 x 1/2"

optional

3шт.

1500496C1

CABLE CLIP

2шт.

3123195R1

CLAMP

CLIP windscreen, frame top

3шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

1шт.

1502019C1

SCREW,Hex Random Sl, #10 - 24 x 1/2"

optional

1шт.

3123195R1

CLAMP

CLIP cab frame, rear, top

2шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

1шт.

1502019C1

SCREW,Hex Random Sl, #10 - 24 x 1/2"

optional

1шт.

3123193R1

TAPE

SPARE PART bulk length

1шт.

705548R1

GROMMET

windscreen, top fillet

2шт.

3118661R1

GROMMET

windscreen, corner fillet

2шт.

3112438R1

GROMMET

light tube support

2шт.

537504R1

CABLE ASSY.

battery earth

1шт.

289862C1

CABLE TIE,3/16" x 7"

CABLE STRAP Harness to fuel line

2шт.

3123431R1

CABLE

1шт.

225-14112

NUT,#12-24

1шт.

160221

SCREW,Cross Pan Hd, #12 - 24 x 1/2"

1шт.

121744

ANGLE

Version without flasher unit, for use with earth lead

1шт.

289862C1

CABLE TIE,3/16" x 7"

CABLE STRAP For use with Ipto crossover tube

1шт.

3123194R1

TAPE

bulk length

1шт.

537024R1

CLIP

cable, radiator guard, L.H.

1шт.

3116918R1

CABLE CLIP

air cleaner bracket

1шт.

100770H

CLIP

grille tie bar

1шт.

120392

WASHER,1/4", SAE

lock

1шт.

3221235R2

RELAY

Bosch, for 4 wheel drive tractors

1шт.
