Запчасти Case IH 684 (02-004) - PRODUCT GRAPHIC, PACKAGE ASSORTED GASKETS Accessories & Attachments / Miscellaneous

Схема запчастей Case IH 684 - (02-004) - PRODUCT GRAPHIC, PACKAGE ASSORTED GASKETS Accessories & Attachments / Miscellaneous

Артикул

Название

Примечание

Количество

1135262R1

PRODUCT GRAPHIC

684 INTERNATIONAL L.H., STANDARD MACHINES

1шт.

1135270R1

PRODUCT GRAPHIC

684 INTERNATIONAL L.H., WHEEL DRIVE

1шт.

1135263R1

PRODUCT GRAPHIC

684 INTERNATIONAL R.H., STANDARD MACHINES

1шт.

1135271R1

PRODUCT GRAPHIC

684 INTERNATIONAL R.H., 4-WHEEL DRIVE

1шт.

1135264R1

PRODUCT GRAPHIC

H84 INTERNATIONAL L.H.

1шт.

1135265R1

PRODUCT GRAPHIC

H84 INTERNATIONAL R.H.

1шт.

1093338R1

PRODUCT GRAPHIC

SPARE PART INTERNATIONAL HYDRO, 268, L.H.

1шт.

1093339R1

PRODUCT GRAPHIC

SPARE PART INTERNATIONAL HYDRO, 268, R.H.

1шт.

533597R1

DECAL

SKIDDED UNIT, NO. PLATE

1шт.

192413

DRIVE SCREW,U, Rnd Hd, Metallic, #2 x 1/4"

4 X 1/4 METAL DRIVE

2шт.

3108310R1

PRODUCT GRAPHIC

SPARE PART MODEL AND SERIAL NUMBER, PLATE

1шт.

192314

SCREW NO. 4 X 1/4 METAL DRIVE

2шт.

1092745R2

DECAL

CAUTION INSTRUCTION

1шт.

533864R1

PRODUCT GRAPHIC

DIESEL FUEL

1шт.

533592R1

PRODUCT GRAPHIC

GOVERNOR CONTROL

1шт.

537665R1

DECAL

TRANSMISSION CONTRO, SYNCHROMESH DRIVE 684

1шт.

1082939R1

TAG

SPEED RATIO CONTROL

1шт.

537666R1

PRODUCT GRAPHIC

TRANSMISSION CONTROL, HYDROSTATIC DRIVE H84

1шт.

537662R1

PRODUCT GRAPHIC

PTO AND RAISE RESPONSE GUIDE 684

1шт.

537663R1

PRODUCT GRAPHIC

DROP RESPONSE GUIDE

1шт.

537664R1

PRODUCT GRAPHIC

DRAFT CONTROL GUIDE

1шт.

1093228R1

PRODUCT GRAPHIC

PATENT

1шт.

533596R1

PRODUCT GRAPHIC

FUEL CONT. DIESEL, UP TO 685/10156

1шт.

1135126R1

PRODUCT GRAPHIC

FUEL CONTROL, 685/10157 UP

1шт.

1093352R1

DECAL

TAG, ALTERNATOR CAUTION

1шт.

1093170R1

PRODUCT GRAPHIC

POWER STG PERSONNEL SAFETY

1шт.

1093171R1

DECAL

PRODUCT OPERATION WARNING INSTRUCTION

1шт.

1135102R1

PRODUCT GRAPHIC

PTO AND RAISE RESPONSE GUIDE 685

1шт.

1135097R1

DECAL

1ST-2ND SPEED 685

1шт.

1135098R1

DECAL

3RD/4TH SPEED 685

1шт.

1135100R1

DECAL

RANGE LOW AND REVERSE 685

1шт.

1135101R1

DECAL

RANGE HIGH 685

1шт.

1135111R1

DECAL

RANGE HIGH-LOW H84

1шт.

1093172R1

PRODUCT GRAPHIC

ENGINE OIL INST

1шт.

1093173R1

PRODUCT GRAPHIC

FUEL FILTER AND WATER SEPARATOR INSTRUCTIONS

1шт.

1093174R1

PRODUCT GRAPHIC

ALTERNATOR

1шт.

1093175R1

PRODUCT GRAPHIC

ANTI-FREEZE

1шт.

1093176R1

PRODUCT GRAPHIC

HYTRAN FLUID

1шт.

1093372R1

PRODUCT GRAPHIC

UP TO 684/8848, H84/2243 AND 268/596

1шт.

1135048R2

PRODUCT GRAPHIC

684/8849, H84/2244 AND 268/597 UP

1шт.

1093373R1

PRODUCT GRAPHIC

1шт.

1135272R1

PRODUCT GRAPHIC

INTERNATIONAL HYDRO 84 L.H

1шт.

1135273R1

PRODUCT GRAPHIC

INTERNATIONAL HYDRO 84 R.H.

1шт.

2254343R1

PRODUCT-GRAPHIC, INTERNATIONAL MACHINES FITTED W/DE-LUXE CAB

1шт.

1093182R1

CAUTION DECAL

CAUTION, MACHINES FITTED W/DE-LUXE CAB

1шт.

1135242R1

PRODUCT GRAPHIC

INTERNATIONAL 685 L.H.

1шт.

1135243R1

PRODUCT GRAPHIC

INTERNATIONAL 685 R.H.

1шт.

1135244R1

PRODUCT GRAPHIC

INTERNATIONAL H85 L.H.

1шт.

1135245R1

PRODUCT GRAPHIC

INTERNATIONAL H85 R.H.

1шт.

1135250R1

PRODUCT GRAPHIC

INTERNATIONAL 685 L.H., Z.F. AXLE

1шт.

1135251R1

PRODUCT GRAPHIC

INTERNATIONAL 685 R.H., Z.F. AXLE

1шт.

1135252R1

PRODUCT GRAPHIC

INTERNATIONAL, HYDRO 85 L.H., Z.F. AXLE

1шт.

1135253R1

PRODUCT GRAPHIC

INTERNATIONAL, HYDRO 85 R.H., Z.F. AXLE

1шт.

530352R92

PACKAGE

HYDROSTATIC TRANSMISSION GASKET SERVICE, CONSISTS OF

1шт.

400949R1

GASKET

BOTTOM COVER

1шт.

400951R1

GASKET

RELIEF VALVE ACCESS COVER

1шт.

400957R1

GASKET,0.76mm Thk

SERVO ACCESS COVER

1шт.

401019R2

GASKET

TOP COVER

1шт.

401028R1

GASKET

CHARGE PUMP MANIFOLD

1шт.

401033R1

GASKET

SUCTION PIPE ELBOW

1шт.

401056R1

GASKET

MULTIPLE VALVE BODY

1шт.

405193R1

GASKET

ACCESS COVER

1шт.

399814R3

GASKET

CLUTCH HOUSING TO REAR FRAME

1шт.

530372R91

O-RING

HYDROSTATIC TRANSMISSION O-RING SERVICE, CONSISTS OF

1шт.

21480R1

O-RING,0.103" Thk x 1.987" ID, -136, Cl 5, 75 Duro

2 X 2-3/16 X 3/32, FRONT PTO BEARING COVER

1шт.

295204R1

O-RING,0.103" Thk x 2.8" ID, -149, Cl 5, 75 Duro

2-3/16 X 3 X 3/32, MOTOR TRUNNION

2шт.

297459R1

O-RING,0.116" Thk x 1.048" ID, -914, Cl 6, 90 Duro

7/8 OD TUBE

1шт.

343943R1

O-RING,6.234" ID x 0.139" Width

6-1/4 X 6-1/2 X 1/8, TRANS CHARGE PUMP

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

9/16 X 3/4 X 3/32, CAM ACTUATING SHAFT

1шт.

360610R1

O-RING,1.609" ID x 0.139" Width

1-5/8 X 1-7/8 X 1/8, PUMP SUCTION PIPE

2шт.

368269R1

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

3/4 OD TUBE, PRESSURE CHECK PLUG

1шт.

369751R1

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

1/4 OD tube, Pressure check plug, Pressure tube elbow, Reg valve housing, Pump servo elbow

4шт.

369384R1

O-RING,0.072" Thk x 0.414" ID, -905, Cl 6, 90 Duro

5/16 OD tube, Motor servo tee, Valve shut-off bolt

2шт.

369908R1

O-RING,0.103" Thk x 0.799" ID, -117, Cl 5, 75 Duro

13/16 X 1 X 3/32, PUMP SERVO TRUNNION

1шт.

372821R1

O-RING,0.103" Thk x 1.049" ID, -121, Cl 5, 75 Duro

1-1/16 X 1-1/4 X 3/32, MOTOR SERVO TRUNNION

1шт.

128359

O-RING,0.07" Thk x 0.614" ID, -16, Cl 5, 75 Duro

5/8 X 3/4 X 1/16, REG VALVE ASSY

1шт.

384377R1

O-RING,0.103" Thk x 2.55" ID, -141, Cl 6, 90 Duro

2-5/16 X 2-1/2 X 3/32, PUMP TRUNNION

2шт.

384937R1

O-RING,0.07" Thk x 0.239" ID, -10, Cl 6, 90 Duro

1/4 X 3/8 X 1/16, PRESSURE CHECK BUSHING, SHUTTLE BLOCK CONNECTORS

3шт.

384943R1

O-RING,0.739" ID x 0.07" Width

Charge Pump Seal, Exhaust Pipe Seal, Charge Jumper Tube

6шт.

388591R1

RING

VALVE HOUSING SEALING

1шт.

401017R1

RING

BACK UP

2шт.

539535R91

O-RING KIT

PACKAGE, BRAKE O-RING SERVICE, CONSISTS OF 2 O-RINGS 343932R1, 2 O-RINGS 21472R1, 2 O-RINGS 289506R1

1шт.

3118117R91

FILTER CARTRIDGE

PACKAGE, FILTER ELEMENT, CONSISTS OF

1шт.

ELEMENT, HYDRAULIC OIL FILTER

6шт.

405462R1

GASKET,147.4mm ID x 154.51mm OD x 2.36mm Thk

Oil filter case

6шт.

375271R1

O-RING,0.426" ID x 0.07" Width

FILTER CASE SEAL

6шт.

3044506R93

FILTER, FUEL

ELEMENT

2шт.

3144477R92

FILTER

ELEMENT, FUEL, OPTIONAL

2шт.

3136046R93

FILTER, ENGINE OIL

FILTER, OIL ASSY, SPIN-ON

6шт.

Выбрано товаров: 89
