Запчасти Case IH 674 (13-11) - BOSTROM SEAT (05) - SUPERSTRUCTURE

528737R91

DRIVER SEAT

ASSY, Bostrom

1шт.

138538

LOCK WASHER

5/16 C-Z int tooth lock

4шт.

160688

SCREW,Cross Pan Hd, 5/16" - 18 x 3/4"

4шт.

1

538693R1

BUTTON

KNOB

1шт.

2

825199C91

SLIDE

RAIL, R.H. with adjuster

1шт.

120376

NUT,5/16"-18, G5

2шт.

160688

SCREW,Cross Pan Hd, 5/16" - 18 x 3/4"

6шт.

80681

LOCK WASHER,5/16"

4шт.

3

538027R1

SPARE PART front mounting

1шт.

4

538694R1

SPRING

1шт.

5

538026R1

SEAT ASSY.

pan

1шт.

6

538028R1

BRACKET

rear mounting

1шт.

7

825198C1

RAIL

slide L.H.

1шт.

120376

NUT,5/16"-18, G5

2шт.

160688

SCREW,Cross Pan Hd, 5/16" - 18 x 3/4"

6шт.

80681

LOCK WASHER,5/16"

4шт.

8

537526R1

BRACKET

ASSY, seat mounting

1шт.
