Запчасти Case IH 674 (13-08) - STEERING SUPPORT (05) - SUPERSTRUCTURE

1

3113302R1

SUPPORT

ASSY, steering

1шт.

179833

BOLT,Hex, 3/8" - 16 x 1/2", Gr 5, Full Thd

4шт.

179841

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

2шт.

103321

LOCK WASHER,3/8"

2шт.

179791

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

4шт.

24539R1

HOLE PLUG BUTTON,1"

1шт.

3113429R1

PLUG

1 in. button, optional

1шт.

660200R1

SPACER,10.7mm ID x 17.14mm OD x 9.5mm L

.375 X .675 X .423, for use between the steering unit and the hand pump bracket, not illustrated

2шт.
