Запчасти Case IH 644 (1H15) - SERVICE PACKAGES FOR RANGE TRANSMISSION 744/844/844S (04) - Drive Train

3147450R96

PACKAGE

for version without power-shift transmission, 25 km consisting of: (-Y9542) G

1шт.

3142472R96

GEAR-SET

of road range, with shims and spacer ring, needle bearings and shims

1шт.

3148605R3

GEAR

sliding, reverse

1шт.

3142463R3

GEAR

field range

1шт.

3147459R1

WASHER

two-piece

1шт.

933946R1

RING, SNAP

RING SNAP CIRCLIP

1шт.

3142461R3

COUNTERSHAFT

rear

1шт.

3216408R1

ROD

range shift

1шт.

3147451R96

KIT

for version without power-shift transmission, 30 km, consisting of: (-Y9542) G

1шт.

3142468R96

GEAR-SET

of road range with shims and spacer ring, needle bearings and shims

1шт.

3148605R3

GEAR

sliding, reverse

1шт.

3142463R3

GEAR

field range

1шт.

3147459R1

WASHER

two-piece

1шт.

933946R1

RING, SNAP

RING SNAP CIRCLIP

1шт.

3142461R3

COUNTERSHAFT

rear

1шт.

3216408R1

ROD

range shift

1шт.

3147452R97

GEAR-SET

for version with power-shift transmission, 25 km, consisting of: (-Y9542) G

1шт.

3142472R96

GEAR-SET

of road range, with shims and spacer ring, needle bearings and shims

1шт.

3217335R3

GEAR

sliding, reverse

1шт.

3142477R3

GEAR

field range

1шт.

3147459R1

WASHER

two-piece

1шт.

933946R1

RING, SNAP

RING SNAP CIRCLIP

1шт.

3142461R3

COUNTERSHAFT

rear

1шт.

3147350R1

WASHER

1шт.

3217313R1

ROD

range shift

1шт.

3147453R97

GEAR-SET

for version with power-shift transmission, 30 km, consisting of: (-Y9542) G

1шт.

3142468R96

GEAR-SET

of road range, with shims and spacer ring, needle bearings and shims

1шт.

3217335R3

GEAR

sliding, reverse

1шт.

3142477R3

GEAR

field range

1шт.

3147459R1

WASHER

two-piece

1шт.

933946R1

RING, SNAP

RING SNAP CIRCLIP

1шт.

3142461R3

COUNTERSHAFT

rear

1шт.

3147350R1

WASHER

1шт.

3217313R1

ROD

range shift

1шт.

3216410R95

GEAR-SET

for version with speed reducer, 25 km, consisting of: (-Y9542) G

1шт.

3148601R92

GEAR-SET

of road range

1шт.

3142463R3

GEAR

field range

1шт.

3148605R3

GEAR

sliding, reverse

1шт.

3148603R93

GEAR-SET

1шт.

3216409R1

SPACER

RING

1шт.

3147668R4

SHAFT

COUNTER, rear

1шт.

3216408R1

ROD

range shift

1шт.

3216411R95

GEAR-SET

for version with speed reducer, 30 km, consisting of: (-Y9542) G

1шт.

3148602R92

GEAR-SET

of road range

1шт.

3142463R3

GEAR

field range

1шт.

3148605R3

GEAR

sliding, reverse

1шт.

3148603R93

GEAR-SET

1шт.

3216409R1

SPACER

RING

1шт.

3147668R4

SHAFT

COUNTER, rear

1шт.

3216408R1

ROD

range shift

1шт.
