Запчасти Case IH 585 (5-332[JDS]) - WHEEL HUB AND DRIVE, FRONT, 4WD PRIOR TO P.I.N. 18001 (05) - STEERING
№
Артикул
Название
Примечание
Количество
1
3216585R1
BUSHING,28mm ID x 32mm OD x 30mm L
(Replaces 3126585R1)
4шт.
2
3405555R1
SEAL
oil, complete, Includes: Ref. 3, 4 and 5
4шт.
3
NSS
NOT SOLD SEPARAT
SEAL felt
1шт.
4
NSS
NOT SOLD SEPARAT
SEAL oil
1шт.
5
NSS
NOT SOLD SEPARAT
HOLDER oil seal
1шт.
6
NSS
NOT SOLD SEPARAT
SHAFT drive, single U-joint, Includes: Ref. 7-10
2шт.
7
1502267C1
SHAFT
right
1шт.
7
1502265C1
DRIVE SHAFT
SHAFT left
1шт.
8
3230277R1
SPIDER ASSY.
SPIDER complete, including bearings
1шт.
9
3223197R1
RING, SNAP
RING retaining, 27 x 1.3 mm
4шт.
10
3216599R91
SHAFT
hub
1шт.
11
82241C91
SHAFT
right drive, double U-joint
1шт.
11
82242C91
SHAFT
left drive, double U-joint, Includes: Ref. 12-16
1шт.
12
89654C1
FORK
long drive shaft, right
1шт.
12
89656C1
FORK
long drive shaft, left
1шт.
13
89653C1
U-JOINT SPIDER
JOINT spider
2шт.
14
89652C1
JOINT
center
1шт.
15
38918
LUBE NIPPLE
NIPPLE, LUBE, M6
1шт.
16
89655C1
FORK
drive shaft, short
1шт.
17
1502272C1
HUB CARRIER
CARRIER hub
2шт.
18
3216594R1
OIL SEAL
SEAL oil
2шт.
19
3216593R1
WASHER
WASHER special
2шт.
20
3230271R91
TAPERED BEARING
BEARING inner
2шт.
21
3230280R1
HUB
wheel
2шт.
22
3230876R1
BOLT,Wheel, Serr, M18 x 1.5 x 61 mm
wheel
16шт.
23
712824R1
LOCK WASHER,M18.5, Spring
WASHER lock
16шт.
24
933800R1
NUT
wheel mounting
16шт.
25
533727R1
BEARING, CUP
BEARING cup
2шт.
25
533726R91
BEARING
cone
2шт.
26
3146675R1
RING, SNAP
RING snap
2шт.
27
3230266R1
RING CARRIER
CARRIER ring gear, 72 teeth
2шт.
28
3230267R1
GEAR, RING
GEAR ring, 72 teeth
2шт.
29
3230269R1
NUT
adjusting
4шт.
30
3230270R1
DISC
RING locking
2шт.
31
3230265R1
GEAR
sun, 18 teeth
2шт.
32
933074R1
SNAP RING,M28, Ext
RING retaining, external, 25.4 mm
2шт.
33
3147209R2
PLUG
PIN thrust
2шт.
34
3147212R1
WASHER
SHIM, 0.3 mm
1шт.
34
3147211R1
WASHER
SHIM, 0.5 mm
1шт.
34
3147210R1
SHIM
1.0 mm
1шт.
34
3147210R1
SHIM
1.0 mm
1шт.
Выбрано товаров: 41
