Запчасти Case IH 530 (152) - ELECTRICAL SYSTEM, PRIOR TO S/N 8262800, 530 MODEL, 188 DIESEL ENGINE (04) - ELECTRICAL SYSTEMS

1

G44890

BATTERY - 6 volt

2шт.

2

G30296

COVER ASSY

COVER - battery

1шт.

3

111-213

CARRIAGE BOLT,Short NK, 5/16"-18 x 9", G2

BOLT - 5/16" x 9" rd. hd. sq. neck

2шт.

4

G30295

BASE - battery

1шт.

5

G49020

NUT

- cover bolt (5/16" N.C. wing)

2шт.

6

A29987

STRAP

- ground (Before SN8232882)

1шт.

6

A36368

STRAP

- ground (SN8232882 and after)

1шт.

7

G44055

CABLE PULLING GRIP

CABLE - jumper, Serial Range: battery-battery

1шт.

8

G46879

COVER

- terminal (marked EL)

2шт.

9

G46880

COVER

- terminal (marked ER)

1шт.

10

G44049

CABLE

- battery to starter (Before SN8232882)

1шт.

10

O3095AB

X

CABLE - battery to starter (SN8232882 and after)

1шт.

11

O3092AB

CLIP - cable to torque tube

1шт.

12

A21753

CAP

NIPPLE - solenoid terminal

1шт.

13

G44927

STARTING MOTOR - (Delco #1107516) Order A36583

1шт.

13

A36582

STARTING MOTOR - (Delco #1107584) Order A36583

1шт.

13

A36583

STARTER MOTOR

STARTING MOTOR - (Delco #1107583) For starting motor repairs see Figure 156

1шт.

14

413-632

BOLT,Hex, 3/8" - 16 x 2", Gr 5

3шт.

15

G46873

GASKET

- starting motor (w/Case-O-Matic)

1шт.

16

G46873

GASKET

SOLENOID - manifold heater

1шт.

17

G44053

X

CABLE - starter solenoid to heater solenoid

1шт.

18

G30577

BRACKET - heater solenoid (w/Power Steering)

1шт.

19

G44067

CABLE - solenoid to heater (Before eng. #2028232)

1шт.

20

G15955

BAR

- heater plug (Before eng. #2028232)

1шт.

21

G45259

PLUG

- manifold heater (Before eng. #2028232)

4шт.

22

131-972

NUT

- lock (Before eng. #2028232)

4шт.

23

A21483

CABLE

- solenoid to heater (Eng. #2028232 and after)

1шт.

24

A37775

HEATER

PLUG - manifold heater (Eng. #2028232 and after) (incl. ref. 25)

1шт.

25

7770

NUT,Hex, 1/4 - 20, Cl 5

- 1/2" N.C. hex (plated)

1шт.

26

A20916

MANIFOLD GASKET

GASKET - heater plug (Eng. #2028232 and after)

1шт.

27

G2098

SUPPORT - generator brkt. (w/o Power Steering)

1шт.

28

13-652

BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5

- 3/8" x 3-1/4" N.C. hex hd.

3шт.

29

A30042

GASKET

-, Serial Range: support-block

1шт.

30

A38746

BRACKET

- generator

1шт.

31

13-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

1шт.

31

13-524

BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5

- 5/16" x 1-1/2" N.C. hex

1шт.

32

G44877

GENERATOR - (Delco #1100385) Order A36563

1шт.

32

A36563

GENERATOR

- (Delco #1100443) Repairs Figure 154

1шт.

33

13-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

2шт.

34

A37017

STRAP

- adjusting, generator

1шт.

35

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

1шт.

36

13-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

1шт.

37

G46238

BELT,0.55" W x 17.78" L

Fan and Generator Drive 0.55" W x 17.78" L

1шт.

38

NLS

NO LONGER SERVICED

- voltage (Delco #11192670 Use only with positive ground generator G44877

1шт.

38

A35233

REGULATOR

- voltage (Delco #1119241)

1шт.

39

14-424

SCREW,Hex, 1/4" - 28 x 1 1/2", Gr 5

BOLT - 1/4" x 1-1/2" N.F. hex hd.

4шт.

40

G44065

CABLE PULLING GRIP

CABLE - master, lower half, 44" long (w/Auto-Lite instrument cluster)

1шт.

41

A35304

HARNESS

CABLE - master, lower half, 44" long (w/Stewart-Warner instrument cluster)

1шт.

42

G44064

CABLE - master, upper half, 19" long (w/Auto-Lite instrument cluster)

1шт.

43

A35305

CABLE

- master, upper half (w/Stewart-Warner instrument cluster)

1шт.

44

A20411

CONDUIT - master cable, 19" long

1шт.

45

25-104

NUT,1/4"-20, G5

2шт.

46

G44051

CABLE PULLING GRIP

WIRE - switch to regulator & ammeter

1шт.

Used with Auto-Lite cluster only

1шт.

47

G44057

WIRE - switch to temp. & fuel guage

1шт.

Used with Auto-Lite cluster only

1шт.
