Запчасти Case IH 530 (278) - ROCKSHAFT AND HOUSING, UTILITY, EAGLE HITCH TRACTOR, PRIOR TO S/N 8262800 (06) - POWER TRAIN

1

A36828

HOUSING

ASSY. - rockshaft (incl. ref. 2 - 10)

1шт.

2

G49663

BUSHING

- L.H., rockshaft

2шт.

3

G49662

BUSHING

- R.H., rockshaft

2шт.

4

A36438

PISTON

ASSY. (incl. ref. 5 & 6)

1шт.

5

A36441

SEAL ASSY.

RING - wear

1шт.

6

A36442

SEAL

RING - seal

1шт.

7

A36405

O-RING,0.139" Thk x 3.484" ID, -238, Cl 6, 90 Duro

"O" RING - cylinder cap

1шт.

8

G16524

CAP - cylinder

1шт.

9

13-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5, Full Thd

6шт.

10

92-8

LOCK WASHER,1/2"

6шт.

11

G10941

GASKET

- housing to trans. case

1шт.

12

138-200

LOCK PIN,1/2" x 1", Slotted

PIN, 1/2" x 1", Slotted

1шт.

13

113-228

X

BOLT - 3/8" x 1-1/4" N.C. hex hd. (Gr. 8)

6шт.

13

113-236

X

BOLT - 3/8" x 2" N.C. hex hd. (Gr. 8)

2шт.

14

113-237

X

BOLT - 3/8" x 4" N.C. hex hd. (Gr. 8)

4шт.

15

92-6

LOCK WASHER,3/8"

12шт.

16

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - 1/8" str.

2шт.

17

G30527

ROD

- rocker arm

1шт.

18

O9018AB

X

"O" RING

1шт.

19

G10940

ARM - rocker, rockshaft

1шт.

20

138-142

LOCK PIN,1/4" x 2", Slotted

PIN, 1/4" x 2", Slotted

2шт.

21

G10460

ROCKSHAFT

1шт.

22

G10471

ARM - lift, L.H.

1шт.

23

G10470

ARM - lift, R.H.

1шт.

24

VT2948

WASHER - retaining, lift arm

2шт.

25

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

2шт.

26

92-6

LOCK WASHER,3/8"

2шт.

27

G17051

QUADRANT - depth control

1шт.

28

171-201

SCREW,Flat Hd, 5/16" x 1/2"

- 5/16" x 1/2" N.C. flat hd.

1шт.

29

G1109

STOP - quadrant

2шт.

30

11-520

X

BOLT - 5/16" x 1-1/4" N.C. rd. hd. sq. nk.

2шт.

31

129-419

WING NUT,5/16"-18

NUT - wing, 5/16" N.C.

2шт.

32

92-5

LOCK WASHER,5/16"

2шт.

33

95-5

WASHER,3/8" x 7/8" x .083"

- 5/16" plain

2шт.

34

G13153

LEVER - depth control

1шт.

35

G46229

ROD - depth control (Before SN 8191147)

1шт.

36

A35201

ROD - depth control (SN 8191147 and after)

1шт.

37

213-3

ADJUSTABLE CLEVIS,5/16"-24

YOKE - control rod

1шт.

38

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

1шт.

39

141-3

CLEVIS PIN,5/16" x .940"

PIN, CLEVIS, , Yoke 5/16" x .940"

2шт.

40

132-26

COTTER PIN

PIN, split (Cotter), 3/32" x 3/4"

2шт.

41

G13109

TUBE - hyd. valve to housing (std. clutch tractor before SN 8191147) 0.5" OD x 36.75" L

1шт.

41

G45147

TUBE - hyd. valve to housing (Case-O-Matic) tractor before SN 8191147)

1шт.

42

G10932

ELBOW

- tube to housing (Before SN 8191147)

1шт.

43

G10934

NIPPLE, LUBE

NIPPLE - elbow (Before SN 8191147)

1шт.

44

G10932

ELBOW

- tube to interlock (Before SN 8191147)

1шт.

45

G45483

HOSE - hyd. valve to housing (dry clutch) tractor SN 8191147 and after)

1шт.

46

G46394

CLIP - hose (SN 8191147 and after)

1шт.

47

A35296

TUBE - hyd. valve to housing (Case-O-Matic) tractor SN 8191147 and after)

1шт.

48

A35297

CLAMP - tube (SN 8191147 and after)

1шт.

49

219-926

ELBOW - housing & interlock (SN 8191147 and after)

2шт.

50

NSS

NOT SOLD SEPARAT

PISTON (w/steel ring) Order A36438 (incl. ref. 51 & 52)

1шт.

51

G4803

RING

- piston (Steel)

1шт.

52

V20353

SCREW

"O" RING (piston w/steel ring)

1шт.

53

G15456

PLUG

- housing oil passage

1шт.

54

VT4846

X

GASKET - plug

1шт.

55

O9214AB

X

SCREW - pivot, R.H. lift link

2шт.

56

193-36

LOCK WASHER,Int Tooth, 7/8"

WASHER, LOCK, Int Tooth, 7/8"

2шт.
