Запчасти Case IH 485 (0F05-2) - CRANKCASE SIDE COVER Power

1

3055394R1

GASKET

SIDE COVER

1шт.

1

3136174R1

GASKET

SIDE COVER - OPTIONAL

1шт.

2

3055313R31

COVER

CRANKCASE SIDE

1шт.

13-510

BOLT,Hex, 5/16" - 18 x 5/8", Gr 5, Full Thd

8шт.

80681

LOCK WASHER,5/16"

8шт.

3

3055574R1

WASHER,8.5mm ID x 19mm OD x 2.5mm Thk

.355 X .748 X .398

8шт.

4

3138687R2

SEALING RING,M8 x 11.5 x 1.5

PACKING

2шт.

5

3144020R91

BREATHER ASSY.

CRANKCASE

1шт.

5

3144789R1

COVER

USED W/VALVE COVER ATTACHMENT

1шт.

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

1шт.

6

3138639R2

GASKET,2mm Thk

BREATHER

1шт.

7

3055324R92

HYDRAULIC OIL FILTER

ELEMENT ASSY, BREATHER

1шт.

8

3144023R1

CLAMP

1шт.

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

1шт.

80681

LOCK WASHER,5/16"

1шт.

9635082

NUT,5/16" - 18, Gr 5

1шт.

9

3144022R1

BRACKET

LINK, FIXING

1шт.

179900

BOLT,Hex, 9/16" - 12 x 3/4", Gr 5

5/16-12 X 3/4 HEX HD CAP

1шт.

80681

LOCK WASHER,5/16"

1шт.

10

3144684R1

COVER

1шт.

933682R1

BELLEVILLE WASHER,M6 Bolt Size x 12.6mm OD x 0.7mm Thk

2шт.

825-1406

NUT,M6, Cl 8

2шт.

11

3144685R1

GASKET

COVER

1шт.

12

3132869R1

O-RING

2шт.

13

3055391R41

RETAINER

1шт.
