Запчасти Case IH 485 (00G14) - NEUTRAL SAFETY SWITCH (06) - ELECTRICAL

Схема запчастей Case IH 485 - (00G14) - NEUTRAL SAFETY SWITCH (06) - ELECTRICAL

Артикул

Название

Примечание

Количество

63-1086

SCREW,Hex Hd, #8-32 x 3/8"

NO 8 X 3/8

1шт.

225-10108

NUT,#8-32

1шт.

492-11008

LOCK WASHER,#8

1шт.

3123109R1

CABLE CLIP

TEMPATURE SENDER

1шт.

100770H

CLIP

GRILLE SHROUD LH

1шт.

3113490R1

CLIP

STEERING SUPPORT LH CHANNEL

1шт.

537025R1

CLIP

HARNESS TO BATTERY SUPPORT

1шт.

316433C1

CLAMP

MAIN HARNESS

1шт.

88574

BOLT,Hex, 5/16" - 18 x 1/2", Gr 5, Full Thd

1шт.

492-11031

LOCK WASHER,5/16"

1шт.

316433C1

CLAMP

MAIN HARNESS

1шт.

413-68

BOLT,Hex, 3/8" - 16 x 1/2", Gr 5

1шт.

492-11038

LOCK WASHER,3/8"

1шт.

537025R1

CLIP

SAFETY START CABLE TO BATTERY TRAY

1шт.

3113490R1

CLIP

HARNESS TO MASTER CYL BRACKET

1шт.

366460R1

CABLE CLIP

FRONT COVER RH REAR

1шт.

537025R1

CLIP

STEERING SUPPORT RH TOP

1шт.

3123195R1

CLAMP

CABLE CAB REAR FRAME

3шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

NO 10-24 X 1/2 TAPTITE HEX WASHER HD

3шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

10-24 X 1/2 HEX (RANDOM SLTD) - OPTIONAL

3шт.

3123195R1

CLAMP

CABLE - LEFT HAND TOP FRAME

3шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

NO 10-24 X 1/2 TAPTITE HEX WASHER HD

3шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

10-24 X 1/2 HEX (RANDOM SLTD) - OPTIONAL

3шт.

3123195R1

CLAMP

CABLE WINDSCREEN TOP FRAME

3шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

NO 10-24 X 1/2 TAPTITE HEX WASHER HD

3шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

10-24 X 1/2 HEX (RANDOM SLTD) - OPTIONAL

3шт.

3123195R1

CLAMP

CABLE - REAR TOP FRAME

2шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

NO 10-24 X 1/2 TAPTITE HEX WASHER HD

2шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

10-24 X 1/2 HEX (RANDOM SLTD) - OPTIONAL - 484, Start Serial: 5683

2шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

10-24 X 1/2 HEX (RANDOM SLTD) - OPTIONAL - 248, Start Serial: 688

2шт.

3123193R1

TAPE

SPARE PART HOSE, CABLE BINDING - BULK LENGTH 15.24 METERS

1шт.

3123158R2

PACKAGE

ALTERNATOR SOCKET

1шт.

705548R1

GROMMET

WINDSCREEN TOP FILLET

2шт.

3118661R1

GROMMET

WINDSCREEN CORNER FILLET

2шт.

531625R1

GROMMET

LIGHT TUBE SUPPORT

2шт.

537504R2

CABLE ASSY.

BATERY TO EARTH

1шт.

289862C1

CABLE TIE,3/16" x 7"

CABLE STRAP BATTERY

2шт.

289862C1

CABLE TIE,3/16" x 7"

CABLE STRAP HARNESS TO FUEL LINE

2шт.

289862C1

CABLE TIE,3/16" x 7"

CABLE STRAP HARNESS TO FUEL PIPE

2шт.

3123431R1

CABLE

TACHO TO FUEL GAUGE EARTH - FLYING LEAD

1шт.

225-14112

NUT,#12-24

NO 12 X 24 HEX MACHINE ZND

1шт.

440-1128

SCREW,Cross Pan Hd, #12-24 x 1/2"

NO 12 X 24 X 1/2 CR ZN PAN HD MACHINE

1шт.

492-11012

LOCK WASHER,#12

For use w/earth harness on machines not fitted w/flasher unit

1шт.

289862C1

CABLE TIE,3/16" x 7"

CABLE STRAP USE W/IPTO CROSSOVER TUBE

1шт.

Выбрано товаров: 44
