Запчасти Case IH 485 (00G13) - CABLE HARNESS AND CONNECTIONS (06) - ELECTRICAL

Схема запчастей Case IH 485 - (00G13) - CABLE HARNESS AND CONNECTIONS (06) - ELECTRICAL

Артикул

Название

Примечание

Количество

3125981R91

HARNESS

MAIN CABLE - SERVICE PARTS ARE: REF. 1 - 4, Start Serial: 5395

1шт.

3125981R91

HARNESS

MAIN CABLE, 248 - SERVICE PARTS ARE: REF. 1 - 4, Start Serial: 647

1шт.

1

3115813R1

FUSE

35 AMP

3шт.

2

3115813R1

FUSE

35 AMP - OPTIONAL

3шт.

3

3118918R1

FUSE

10 AMP

2шт.

4

3118918R1

FUSE

10 AMP - OPTIONAL

2шт.

3123157R1

COVER

FUSE BOX, INCLUDES: REF. 5 - 7

1шт.

5

3123158R2

PACKAGE

ALTERNATOR PLUG CONNECTIONS - AS REQUIRED

1шт.

6

3123724R1

SLEEVE

1шт.

7

3129948R1

BOX, FUSE

PACKAGE - AS REQUIRED

1шт.

3123110R91

HARNESS

MAIN CABLE, 484 - SERVICE PARTS ARE: REF. 8 - 11, Serial Range: -5394

1шт.

3123110R91

HARNESS

MAIN CABLE, 248 - SERVICE PARTS ARE: REF. 8 - 11, Serial Range: -646

1шт.

8

3115813R1

FUSE

35 AMP

3шт.

9

3115813R1

FUSE

35 AMP - OPTIONAL

3шт.

10

3118918R1

FUSE

10 AMP

2шт.

11

3118918R1

FUSE

10 AMP - OPTIONAL

2шт.

3123157R1

COVER

FUSE BOX, INCLUDES: REF. 12 - 14

1шт.

12

3123158R2

PACKAGE

ALTERNATOR PLUG CONNECTIONS - AS REQUIRED

1шт.

13

3123724R1

SLEEVE

1шт.

14

3129948R1

BOX, FUSE

PACKAGE - AS REQUIRED

1шт.

3125768R1

HARNESS

MAIN

1шт.

3125769R1

HARNESS

FRONT - SUPER DE-LUXE CAB

1шт.

3123138R3

HARNESS

CAB LIGHTING, 484, Serial Range: -5682

1шт.

3123138R3

HARNESS

CAB LIGHTING, 248, Serial Range: -687

1шт.

3125877R1

HARNESS

CAB LIGHTING, 484, Start Serial: 5683

1шт.

3125877R1

HARNESS

CAB LIGHTING, 248, Start Serial: 688

1шт.

3123139R2

CABLE

CAB HARNESS TO SIDE LIGHTS FLYING LEAD

1шт.

82985C1

CABLE ASSY.

BATTERY TO STARTER

1шт.

3123190R2

CABLE ASSY.

FLEXIBLE EARTH LEAD - CAB MOUNTING

1шт.

705896R1

CONNECTOR, ELEC

CONNECTOR TACHO

1шт.

705897R1

CONNECTOR, ELEC

CONNECTOR SPEEDO

1шт.

539015R1

CLIP

STEERING SUPPORT L H TOP

1шт.

289862C1

CABLE TIE,3/16" x 7"

CABLE STRAP MAIN HARNESS TO INST SHROUD

2шт.

413-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

2шт.

7770

NUT,Hex, 1/4 - 20, Cl 5

2шт.

492-11025

LOCK WASHER,1/4"

2шт.

495-11028

WASHER,1/4", SAE

(.281 x .625 x .051")

2шт.

3116240R1

CLIP

BATTERY CABLE

1шт.

Выбрано товаров: 38
