Запчасти Case IH 485 (0I22) - SAFETY FRAME, MACHINES FITTED WITH CAB (05) - SUPERSTRUCTURE

Схема запчастей Case IH 485 - (0I22) - SAFETY FRAME, MACHINES FITTED WITH CAB (05) - SUPERSTRUCTURE

Артикул

Название

Примечание

Количество

1

3116153R2

STEP

FOOT ASSY

2шт.

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

4шт.

425-106

NUT,3/8"-16, Cl 5

4шт.

492-11038

LOCK WASHER,3/8"

4шт.

2

3116149R3

PLATFORM

LH

1шт.

3112992R1

NUT

INSERT 1/4-20

6шт.

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

6шт.

425-106

NUT,3/8"-16, Cl 5

4шт.

492-11038

LOCK WASHER,3/8"

6шт.

495-11041

WASHER,0.406" ID x 0.812" OD x 0.065" W

.406 ID X .812 OD X .051 PLN

6шт.

3

3116180R1

GROMMET

PLATFORM LH

1шт.

4

3116150R3

PLATFORM

RH

1шт.

3112992R1

NUT

INSERT 1/4-20

6шт.

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

5шт.

425-106

NUT,3/8"-16, Cl 5

6шт.

492-11038

LOCK WASHER,3/8"

6шт.

495-11041

WASHER,0.406" ID x 0.812" OD x 0.065" W

.406 ID X .812 OD X .051 PLN

6шт.

413-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

1шт.

5

3121998R2

FENDER

AND FRAME ASSY, RH

1шт.

6

3121996R1

FILLER

SPARE PART REAR SIDE TUBE PANEL

2шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

NO 10-24 X 50 TAPTITE HEX WASHER HD

4шт.

401499R1

SELF-TAP SCREW,Hex Wash Hd, #10-24 x 1/2"

10-24 X 1/2 HEX (RANDOM SLTD) - OPTIONAL

4шт.

7

3121970R93

FRAME ASSY

SAFETY - ON ORDERS FOR R91 ORDER 3121970R92 W/TWO PIVOT 3125245R1 RETAINER 3125246R1 AND CLIP 3053111R1

1шт.

326-1264

BOLT,Hex, 3/4" - 10 x 4", Gr 8

4шт.

425-1012

NUT,3/4"-10, G5

Frame to Fenders

4шт.

8

3123059R1

SEAL

FRAME TO FENDER - BULK LENGTH 150 FEET

2шт.

9

3121997R3

FENDER

AND FRAME ASSY, LH

1шт.

3125820R1

SLEEVE

PVC - FOR USE W/FENDER AND FRAME ASSY'S (NOT ILLUSTRATED)

2шт.

Выбрано товаров: 28
