Запчасти Case IH 474 (06-05[1]) - BLOWER FAN Cooling

1

527473R1

FAN

BLADE, ASSY, FAN - HYDROSTATIC DRIVE TRACTORS

1шт.

181312

BOLT,Hex, 1/4" - 28 x 11/16", Gr 5

4шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

4шт.

2

527472R1

FAN

BLADE, ASSY, FAN - SYNCHROMESH DRIVE TRACTORS

1шт.

181312

BOLT,Hex, 1/4" - 28 x 11/16", Gr 5

4шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

4шт.

3

527470R1

V-BELT

BELT, PULLEY

1шт.

4

401124R1

PULLEY

WATER PUMP

1шт.
