Запчасти Case IH 470 (018) - CAMSHAFT AND FLYWHEEL, 470 (148B) SPARK IGNITION ENGINE (02) - ENGINE

Схема запчастей Case IH 470 - (018) - CAMSHAFT AND FLYWHEEL, 470 (148B) SPARK IGNITION ENGINE (02) - ENGINE
10
1
4
33
16
24
6
19
13
26
11
31
29
2
28
16
27
21
25
23
32
12
17
15
14
14
5
34
9
3
22
8
30
15
18
20
7

Артикул

Название

Примечание

Количество

1

A144358

FLYWHEEL

ASSY. (includes ref. 2)

1шт.

2

G11710

GEAR

- ring (135 T)

1шт.

3

A37216

BOLT

- place, flywheel (7/16 x 2" N.F. hex Gr. 8)

4шт.

4

A37647

OIL SEAL

- oil, flywheel

1шт.

5

49482

SNAP RING,2.125", Int, #212

RING, snap, , flywheel brg. 2.125", Int, #212

1шт.

6

T17389

BALL BEARING,1.1811" ID x 2.1654" OD x 0.5118"

BEARING - flywheel

1шт.

7

A37646

O-RING,2.237" ID x 2.443" OD x 0.103"

RING - seal, flywheel bearing

1шт.

8

A39027

OIL SEAL

- oil, crankshaft rear

1шт.

9

A38390

RETAINER

- oil seal

1шт.

10

113-25

X

BOLT - 1/4 x 3/4" N.C. hex (Gr. 8)

4шт.

10

113-26

BOLT

- 1/4 x 1" N.C. hex (Gr. 8)

3шт.

11

924

TOOL KIT

WASHER - lock, 1/4"

7шт.

12

A38196

GASKET

- retainer, rear oil seal

1шт.

13

A37210

CRANKSHAFT

1шт.

14

G37051

KIT

LINERS - rear bearing (Set of 2 Std.)

1шт.

14

G37052

KIT

LINERS - rear bearing (Set of 2 .002" undersize)

1шт.

14

G37053

KIT

LINERS - rear bearing (Set of 2 .020" undersize)

1шт.

14

G37054

KIT

LINERS - rear bearing (Set of 2 .040" undersize)

1шт.

15

G37047

KIT

LINERS - center bearing (Set of 2 std.)

1шт.

15

G37048

KIT

LINERS - center bearing (Set of 2 .002 undersize)

1шт.

15

G37049

KIT

LINERS - center bearing (Set of 2 .020" undersize)

1шт.

15

G37050

KIT

LINERS - center bearing (Set of 2 .040" undersize)

1шт.

16

G37043

KIT

LINERS - front bearing (Set of 2 std.)

1шт.

16

G37044

KIT

LINERS - front bearing (Set of 2 .002" undersize)

1шт.

16

G37045

KIT

LINERS - front bearing (Set of 2 .020" undersize)

1шт.

16

G37046

KIT

LINERS - front bearing (Set of 2 .040" indersize)

1шт.

17

G2037

CAP

- rear bearing liner

1шт.

18

G2036

CAP

- center bearing liner

1шт.

19

G2035

CAP

- front bearing liner

1шт.

20

G49037

BOLT

- bearing cap (1/2 x 3")

4шт.

21

G49059

BOLT

- frt. brg. cap & oil pump (1/2 x 4 3/4")

2шт.

22

126-216

WOODRUFF KEY,Hi-Pro, 1" Dia x 1/4" x 1 1/16"

KEY - pulley & gear to crankshaft (1/4 x 1-1/16" Hi-Pro)

2шт.

23

A29293

SHIM,.010" Thk

Thrust .010" Thk

1шт.

24

A24294

SPACER - thrust

1шт.

25

A29263

GEAR

- crankshaft (24T)

1шт.

26

A29259

SLINGER

- oil

1шт.

27

A36609

OIL SEAL

- oil, crankshaft front

1шт.

28

G11342

X

PULLEY - drive belt, fan & alternator

1шт.

29

A35673

NUT

-, Serial Range: pulley-crankshaft

1шт.

30

D140524

FLEXIBLE COUPLING,13T

COUPLING ASSY. - flexible (includes ref. 31)

1шт.

31

G36905

BLOCK

BUSHING - flex

4шт.

32

13-724

BOLT,Hex, 7/16" - 14 x 1-1/2", Gr 5

Hex, 7/16"-14 x 1 1/2, G5

4шт.

33

92-7

LOCK WASHER,7/16"

4шт.

34

A30013

WASHER,11.51mm ID x 19.05mm OD x 1.59mm Thk

- plain (29/64 x 3/4" x 16 ga.)

4шт.

Выбрано товаров: 44
