Запчасти Case IH 444 (6-11) - BELT PULLEY AND SHIELD ATTACHMENT (09) - CHASSIS

3067897R91

ATTACHMENT, belt pulley, 573 r.p.m. (As required)

1шт.

3067899R91

ATTACHMENT, belt pulley, 783 r.p.m. (As required)

1шт.

3067901R91

ATTACHMENT, belt pulley, 1050 r.p.m.(As required)

1шт.

3067898R91

"ATTACHMENT, w/safety shield, belt pulley" 573 r.p.m. (As required)

1шт.

3067900R91

"ATTACHMENT, w/safety shield, belt pulley" 783 r.p.m. (As required)

1шт.

3067902R91

"ATTACHMENT, w/safety shield, belt pulley" 1050 r.p.m. (As required) comprising: BELT PULLEY SAFETY SHIELD (See detail list) BELT PULLEY

1шт.

1

NOT

APPLICABLE

1шт.

2

NOT

APPLICABLE

1шт.

3

76491H

BEARING, BALL,35 mm ID x 72 mm OD x 17 mm W

"BEARING, ball, belt pulley shaft - outer" (S.K.F.) (Optional)

1шт.

3

700311R91

BEARING, BALL,35 mm ID x 72 mm OD x 17 mm

"BEARING, ball, belt pulley shaft - outer" (Fischer) (Optional)

1шт.

3

701445R91

BEARING, BALL

"BEARING, ball, belt pulley shaft - outer" (Durkopp) (Optional)

1шт.

3

700545R91

BEARING

"BEARING, ball, belt pulley shaft - outer" (Koyo) (Optional)

1шт.

3

704769R92

BEARING, BALL,35 mm ID x 72 mm OD x 17"

"BEARING, ball, belt pulley shaft - outer" (Hoffman) Opt.

1шт.

3

659473R91

BEARING, BALL

"BEARING, ball, belt pulley shaft - outer Opt."

1шт.

3

3108784R91

BEARING, BALL

"BEARING, ball, belt pulley shaft - outer" (NTN) Opt.

1шт.

4

NOT

APPLICABLE

1шт.

5

NOT

APPLICABLE

1шт.

6

3067908R1

GEAR

"GEAR, belt pulley bevel (573 r.p.m.)"

1шт.

6

3067909R1

GEAR

"GEAR, belt pulley bevel (783 r.p.m.)"

1шт.

7

3067911R1

SHIM

"SHIM, belt pulley bevel gear (.0068")"

1шт.

8

3067905R11

CLUTCH

"CLUTCH, cpte., belt pulley P.T.O." (573 and 783 r.p.m.)

1шт.

181333

BOLT,Hex, 5/16" - 24 x 5/8", Gr 5

1шт.

115548

LOCK WASHER,Int Tooth, 5/16"

WASHER, LOCK, Int Tooth, 5/16"

1шт.

9

NOT USED

1шт.

10

20161D

BEARING, BALL,50 mm ID x 90 mm OD x 20 mm

"BEARING, ball, belt pulley shaft - inner" (S.K.F.)

1шт.

10

706234R91

PIPE

"BEARING, ball, belt pulley shaft - inner" (Fischer)

1шт.

10

704235R91

BALL BEARING

"BEARING, ball, belt pulley shaft - inner" (R & M)

1шт.

10

3048701R91

BALL BEARING

"BEARING, ball, belt pulley shaft - inner" (Hoffman)

1шт.

11

704229R91

OIL SEAL

"OIL SEAL, belt pulley drive housing Opt."

1шт.

11

704230R91

SEAL

"OIL SEAL, belt pulley drive housing Opt."

1шт.

11

3066615R91

OIL SEAL,50mm ID x 80.15mm OD x 10mm Thk

"OIL SEAL, belt pulley drive housing Opt."

1шт.

12

444592R1

PLUG

"PLUG, 3/4" pipe Opt."

1шт.

12

20963R1

PLUG,Sq Hd, 1/4"-14 NPTF

"PLUG, 3/4" pipe Opt."

1шт.

13

711882R1

GASKET

"GASKET, belt pulley drive housing top cover" plate.

1шт.

14

711881R1

PLATE

"PLATE, belt pulley drive housing top cover"

1шт.

179836

SCREW,Hex, 3/8" - 16 x 11/16"

" BOLT, 3/8" x 11/16" hex. hd."

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

15

3067904R1

HOUSING

"HOUSING, belt pulley drive"

1шт.

179883

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

1шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

1шт.

16

3067915R1

SHAFT

"PINION and SHAFT, belt pulley drive bevel" (783 r.p.m.)

1шт.

16

704242R1

GEAR

"PINION and SHAFT, belt pulley drive bevel" (573 r.p.m.)

1шт.

17

117991

WOODRUFF KEY,#D, 5/16" x 1 1/4", HT

1шт.

18

3114942R92

"BEARING, ball, belt pulley pinion - inner" (NTN) (Optional)

1шт.

18

49533H

BEARING, BALL

"BEARING, ball, belt pulley pinion - inner" (S.K.F.) (Optional)

1шт.

18

700521R91

BALL BEARING

"BEARING, ball, belt pulley pinion - inner" (Fischer) (Optional)

1шт.

18

700523R91

BEARING, BALL

"BEARING, ball, belt pulley pinion - inner" (R & M) (Optional)

1шт.

18

704768R92

BALL BEARING

"BEARING, ball, belt pulley pinion - inner" (Hoffman) (Optional)

1шт.

19

704243R1

SPACER

"SPACER, belt pulley bearing"

1шт.

20

3073348R1

SHIM

"SPACER, belt pulley pinion shaft (.002) (As required)"

1шт.

20

706745R1

SPACER

"SPACER, belt pulley pinion shaft (.148) (As required)"

1шт.

21

133606H

BEARING, BALL

"BEARING, ball, belt pulley pinion - outer" (S.K.F.) Optional

1шт.

21

704224R91

BALL BEARING

"BEARING, ball, belt pulley pinion - outer" (Fischer) Optional

1шт.

21

704245R91

BEARING

ball, belt pulley pinion - outer (R & M) Optional

1шт.

21

3063609R91

BALL BEARING

BEARING, ball, belt pulley pinion - outer (Hoffman) Optional

1шт.

22

711872R1

GASKET

belt pulley pinion shaft retainer

1шт.

23

704246R21

RETAINER

w/OIL SEAL 704247R91 cpte., belt pulley pinion shaft

1шт.

17984

BOLT, 3/8" x 1-1/8" hex. hd.

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

24

704247R91

OIL SEAL

belt pulley pinion shaft retainer Optional

1шт.

24

704248R91

SEAL

OIL SEAL, belt pulley pinion shaft retainer Optional

1шт.

24

3066620R91

SEAL

OIL SEAL, belt pulley pinion shaft retainer Optional

1шт.

25

704249R11

PULLEY

w/BUSHING 704250R1 cpte., belt

1шт.

704250R1

BUSHING

1шт.

26

704251R1

WASHER

belt pulley retainer

1шт.

27

704252R1

NUT

belt pulley pinion shaft

1шт.

108643

COTTER PIN,5/32" x 1 3/8"

Pin, Split (Cotter), 5/32" x 1 3/8"

1шт.

28

3073827R1

COVER

belt pulley drive housing

1шт.

179841

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

6шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

6шт.

29

3073828R1

SHIM

housing

1шт.

181360

BOLT,Hex, 3/8" - 24 x 3/4", Gr 5

3/8" x 3/4" hex. hd.

8шт.

115549

LOCK WASHER,Int Tooth, 3/8"

WASHER, LOCK, Int Tooth, 3/8"

8шт.

179838

BOLT,Hex, 3/8" - 16 x 7/8", Gr 5, Full Thd

3шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, (Used w/Belt Pulley S/Shield) 3/8"

3шт.

1084129

TAG, "Unit is drained"

1шт.

3049002R92

ATTACHMENT, belt pulley w/SAFETY SHIELD 573 and 783 r.p.m. (As required) comprising: (Domestic only) BELT PULLEY, SAFETY SHIELD (See detail list)

1шт.

3114266R91

ATTACHMENT, belt pulley 573 and 783 r.p.m. (As required) comprising (Export only) BELT PULLEY

1шт.
