Запчасти Case IH 444 (5-13) - SELF SEALING COUPLING ATTACHMENT (08) - HYDRAULICS

3048413R92

COUPLING

ATTACHMENT, self sealing coupling Can only be used when tractor is fitted with Hydraulic Lift Attachment (Vary Touch)

1шт.

1

705512R1

BOLT,1/2"-14 x 1 5/8"

self sealing coupling

1шт.

2

704337R1

SEALING WASHER

WASHER, Dowty, 1/2" BSP

2шт.

3

3048414R91

PIPE

assy., self sealing coupling

1шт.

4

752286R1

NUT

lock, 1/2" BSP

1шт.

5

3065076R11

SUPPORT

"BRACKET, self sealing coupling"

1шт.

NLS

NO LONGER SERVICED

1шт.

6

551658R1

WASHER

"WASHER, plain, 25/32" x 1-1/4" x 22 ga To be used as required

1шт.

6

Q3501

WASHER

"WASHER, plain, 25/32" x 1-1/4" x 16 ga To be used as required

1шт.

6

575813R1

WASHER

"WASHER, plain, 25/32" x 1-1/4" x 11 ga To be used as required

1шт.

7

3041962R91

COUPLING, BREAK AWAY

"COUPLING, self sealing, male half" comprising:

1шт.

3045135R1

RING

"O" RING

1шт.

3045134R1

"SLEEVE, sub. assy.,"

1шт.

3045136R1

SLEEVE

"SLEEVE, tubular"

1шт.

3045137R1

SPRING

1шт.

7

705579R91

COUPLING

"COUPLING, self sealing (Dowty) male half" comprising:

1шт.

3045140R1

RING

"O" RING

1шт.

3045138R1

"SPRING, locking

1шт.

3045139R1

"SPRING, valve (male half)"

1шт.

3045141R1

VALVE

1шт.

3045142R91

SLEEVE

" SLEEVE, assy., valve"

1шт.

8

705578R1

CYLINDER END CAP

"CAP, coupling, dust Opt."

1шт.

8

3041963R1

CAP

"CAP, dust Opt."

1шт.
