(3-05[1]) - SIDE AND REAR LAMP - ELECTRICAL

Запчасти Case IH 434 (3-05[1]) - SIDE AND REAR LAMP - ELECTRICAL (04) - ELECTRICAL SYSTEMS

Схема запчастей Case IH 434 - (3-05[1]) - SIDE AND REAR LAMP - ELECTRICAL (04) - ELECTRICAL SYSTEMS
5
7
3
11
10
9
6
2
8
12
6
1
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

3065309R91

LAMP

side and rear (12V - 6 W) (Yellow), up to 434D/10699 opt., comprising: Ref. 1 - 11

1шт.

Including up to 434P/1361 and 434NT/713

1шт.

708348R91

LIGHT ASSY.

LAMP, side and rear (12 V - 6 W) (Black) up to 434D/10699 opt., comprising: Ref. 1 - 11

1шт.

Including up to 434P/1361 and 434NT/713

1шт.

1

708419R1

GASKET

MOUNT, lens

2шт.

2

708418R1

LENS

red

1шт.

3

707022R91

NO LONGER SERVICED

BULB

1шт.

4

SHELL, adaptor, order 3106554R91

1шт.

5

3060303R1

WASHER, locking

1шт.

6

3060304R1

NUT

2шт.

7

WASHER, shakeproof, order 3106554R91

1шт.

8

3060302R91

CONTACT

assy.

1шт.

9

707131R1

NUT

shell coupling

1шт.

10

708421R1

BODY

1шт.

11

708420R1

LENS

clear

1шт.

3106554R91

ADAPTER

BODY, adaptor assy., w/NUT 707131R1

1шт.
