(2-14) - DISTRIBUTOR COMPLETE, WITH TACHOMETER DRIVE, 7953140 - GAS ENGINE

Запчасти Case IH 434 (2-14) - DISTRIBUTOR COMPLETE, WITH TACHOMETER DRIVE, 7953140 - GAS ENGINE (02) - ENGINE

Схема запчастей Case IH 434 - (2-14) - DISTRIBUTOR COMPLETE, WITH TACHOMETER DRIVE, 7953140 - GAS ENGINE (02) - ENGINE
1
5
8
6
12
2
3
7
10
11
4
9
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

3068973R91

DISTRIBUTOR

w/Tachometer drive, cpte., comprising: Ref. 1 - 12, (order 3068973R92)

1шт.

1

3069777R1

CAP

distributor

1шт.

2

3069778R1

ROTOR

1шт.

3

3069779R91

BREAKER

assy., contact

1шт.

3069883R91

CONDENSER

1шт.

3069884R91

ELECTRICAL WIRE

LEAD, L.T. with Grommet

1шт.

3069882R91

BREAKER POINTS

SET contact

1шт.

4

3069783R91

SPRING

advance weight set

1шт.

5

3069782R91

CAM

MAINSHAFT and Cam assy.

1шт.

6

3069785R1

CLIP

cap

1шт.

7

3069787R1

HOUSING

1шт.

8

3069788R1

WASHER

drive rear thrust

1шт.

9

3069789R1

GEAR

drive

1шт.

10

3069790R1

PLUG

1шт.

11

3069791R91

CLAMP assy., housing

1шт.

12

3069794R1

COUPLING, BREAK AWAY

COUPLING

1шт.

3069881R91

KIT, sundry parts

1шт.
