Запчасти Case IH 434 (6-028) - BOSTROM SUSPENSION SEAT ATTACHMENT - ATTACHMENTS (09) - CHASSIS

ATTACHMENT, Bostrom Suspension Seat, factory application

1шт.

Basic on 434 Petrol & 434 Hi-Clear Petrol

1шт.

3074216R91

ATTACHMENT, Bostrom Suspension Seat, 434/15120 up

1шт.

3072964R91

ATTACHMENT, Bostrom Suspension Seat, Serial Range: up-434/15119

1шт.

1

3070782R1

HOUSING

hyd. lift

1шт.

2

3070785R91

PLATE cpte., reg. number, for factory application Bostrom suspension seat attachment and 3074216R91 and 3072964R91

1шт.

3070787R1

CABLE, reg. plate, for 3072964R91

1шт.

3071675R91

CABLE, reg. number plate flying lead, for factory application Bostrom suspension seat attachment and 3074216R91

1шт.

705896R1

CONNECTOR, ELEC

CONNECTOR, 2 way, for factory application Bostrom suspension seat attachment and 3074216R91

2шт.

705548R1

GROMMET

cover terminal, for factory application Bostrom suspension seat attachment and 3074216R91

1шт.

3070784R92

SUSPENSION

SEAT suspension (see detail list), for factory application Bostrom suspension seat attachment and 3074216R91 and 3072964R91

1шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8" x 1", hex-hd.

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

705545R1

TERMINAL, cover, for factory application Bostrom suspension seat attachment and 3074216R91

1шт.

706102R1

SCREW, 3/16" x 5/8" rd-hd., sltd.

1шт.

114603

WASHER,Ext Tooth, #10

No. 10, lock

1шт.
