Запчасти Case IH 434 (4-34A) - PACKAGES - CHASSIS (09) - CHASSIS

751905R91

GASKET

PACKAGE, chassis gasket (Diesel), comprising all parts listed below

1шт.

703913R3

GASKET,0.79mm Thk

rear axle carrier

2шт.

709109R1

GASKET

rear axle brg. retainer

2шт.

703967R2

GASKET

trans. case cover rear

1шт.

703969R1

GASKET

trans. case cover front

1шт.

703971R1

GASKET

P.T.O. shaft opening cover plate

1шт.

711312R1

GASKET

P.T.O. shifter shaft hole cover plate

1шт.

703921R1

GASKET

front wheel hub cap

2шт.

703987R1

GASKET, trans. countershaft front bearing cage

2шт.

704017R1

GASKET

trans. driving shaft bearing cage

1шт.

711254R1

GASKET

trans. driving shaft oil seal retainer

1шт.

704613R1

GASKET

exhaust pipe flange

1шт.
