Запчасти Case IH 434 (5-22) - PACKAGES, FIELD IMPROVEMENT - HYDRAULIC ATTACHMENTS (08) - HYDRAULICS

3063930R93

PACKAGE, field improvement used w/Vary, Touch Control, comprising adaptor, O-rings, block, bolts, washers, clamp, nut, clip, filter, hoses, manifold, plate, pipes, pump, ring and taps

1шт.

3063920R1

ADAPTER

ADAPTOR

4шт.

570828R1

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

4шт.

3063912R91

BLOCK

cpte., relief valve assy.

1шт.

179839

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

706405R1

CLAMP

pipe

2шт.

179801

BOLT,Hex, 1/4" - 20 x 1 1/2", Gr 5

1шт.

109084

NUT,1/4"-20, G5

1шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

3040744R91

CLIP, hose

8шт.

3062073R93

FILTER

suction

1шт.

3062074R1

HOSE

connecting

4шт.

3063927R91

HOSE

pressure (power steering)

1шт.

3063923R1

MANIFOLD, cpte., suction

1шт.

704348R1

O-RING,0.139" Thk x 1.687" ID, Cl 5

O-RING, suction filter

1шт.

3063928R1

PLATE, support, relief valve

1шт.

NLS

NO LONGER SERVICED

7/16" x 1-1/2" hex-hd.

2шт.

3063925R11

PIPE, cpte., pressure

1шт.

3063921R1

PIPE, suction, front

1шт.

3063922R1

PIPE, suction, rear

1шт.

3063911R91

PUMP

dual

1шт.

705519R1

RING

sealing

1шт.

106794

VALVE

TAP, drain optional

1шт.

707888R92

COCK

TAP, drain optional

1шт.

3063932R93

PACKAGE, field improvement used w/Mech, Depth Control, comprising adaptor, O-rings, block, bolts, washers, clamp, nut, clip, filter, hoses, manifold, plate, pipes, pump, ring and taps

1шт.

3063920R1

ADAPTER

ADAPTOR

4шт.

570828R1

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

4шт.

3063912R91

BLOCK

cpte., relief valve assy.

1шт.

NLS

NO LONGER SERVICED

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

706405R1

CLAMP

pipe

2шт.

179801

BOLT,Hex, 1/4" - 20 x 1 1/2", Gr 5

1шт.

109084

NUT,1/4"-20, G5

1шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

3040744R91

CLIP, hose

8шт.

3062076R93

FILTER, suction, cpte.

1шт.

3062074R1

HOSE

connecting

4шт.

3063927R91

HOSE

pressure (power steering)

1шт.

3063923R91

MANIFOLD

cpte., suction

1шт.

704348R1

O-RING,0.139" Thk x 1.687" ID, Cl 5

O-RING, suction filter

1шт.

3063928R1

PLATE, support, relief valve

1шт.

179862

BOLT,Hex, 7/16" - 14 x 1 1/2", Gr 5

7/16" x 1-1/2" hex-hd.

2шт.

3063929R11

PIPE, cpte., pressure

1шт.

3063921R1

PIPE, suction, front

1шт.

3063922R1

PIPE, suction, rear

1шт.

3063911R91

PUMP

dual

1шт.

705519R1

RING

sealing

1шт.

106794

VALVE

TAP, drain optional

1шт.

707888R92

COCK

TAP, drain optional

1шт.

3070853R91

LEVER

PACKAGE, P.T.O. Shifter lever conversion

1шт.

3069031R92

LEVER

cpte., P.T.O. hand, package, shifter lever, conversion

1шт.
