(1-08) - AIR INTAKE MANIFOLD - DIESEL ENGINE

Запчасти Case IH 434 (1-08) - AIR INTAKE MANIFOLD - DIESEL ENGINE (02) - ENGINE

Схема запчастей Case IH 434 - (1-08) - AIR INTAKE MANIFOLD - DIESEL ENGINE (02) - ENGINE
2
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

704162R1

MANIFOLD GASKET

air intake manifold

2шт.

2

3071625R1

MANIFOLD

air intake BD-154/72327 up

1шт.

2

3070383R1

INLET MANIFOLD

MANIFOLD, air intake

1шт.

Order 3071625R1 w/ HOSE 3071263R1

1шт.

279841

SCREW

BOLT, 3/8" x 1-1/4"

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.
