Запчасти Case IH 434 (6-062) - HEAVY DUTY BACK END ATTACHMENT - ATTACHMENTS (06) - POWER TRAIN

3068865R93

ATTACHMENT, heavy duty back end, comprising:

1шт.

3110729R1

AXLE

rear

2шт.

3069762R11

HOUSING

AXLE, cpte., rear w/eight BOLT 3047576R2

1шт.

On orders for AXLE 3069762R11 furnish AXLE 3110729R1 together w/ eight BOLT 3047576R2

1шт.

3047576R2

BOLT

rear wheel hub

16шт.

3073799R92

CASE

cpte., trans., comprising:

1шт.

3072136R1

BUSHING

BUSH, reverse idler gear, front

1шт.

711272R2

BUSHING

BUSH, reverse idler gear, rear

1шт.

332040

LUBE NIPPLE,90 Degree, 1/8" NPT x .84" lg

LUBRICATOR, 1/8" PTF x 90 degree angle

2шт.

141284

PIN,25.4mm OD x 31.75mm L

Pin 1/2" x 1 1/8"

2шт.

438159

DRAIN PLUG,Sq Hd, 1/2"-14 NPTF

PLUG, 1/2" sq-hd., pipe, opt.

3шт.

217-519

DRAIN PLUG,Sq Hd, 1/2"-14 NPTF

PLUG, , Pipe - Optional Sq Hd, 1/2"-14 NPTF

3шт.

172575

PLUG,Exp, 1 9/16"

1-9/16" dia. expansion

1шт.

3074046R1

CARRIER, rear axle L.H.

1шт.

3074047R1

CARRIER, rear axle R.H.

1шт.

179886

BOLT,Hex, 1/2" - 13 x 1 5/8", Gr 5

1/2" x 1-5/8" hex-hd.

20шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

20шт.

703916R91

SEAL

rear axle oil, optional

1шт.

703917R91

SEAL

rear axle oil, optional

1шт.

3069987R91

SEAL

rear axle oil, optional

1шт.

703915R1

WASHER,2.56mm ID x 3.13mm OD x 0.25mm Thk

rear axle felt

2шт.

709109R1

GASKET

rear axle bearing retainer

2шт.

709110R11

RETAINER

rear axle bearing cpte., w/SEAL 703916R91 & WASHER 703915R1

1шт.

179827

FRONT AXLE

8шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

3071414R91

PACKAGE service, bull pinion shaft bearing cage and shims, comprising:

1шт.

3071401R11

CAGE

w/SEAL 703908R92 cpte., bull pinion shaft bearing L.H.

1шт.

3071402R11

CAGE

w/SEAL 703908R92 cpte., bull pinion shaft bearing R.H.

1шт.

3071403R1

BOLT,Hex, 7/16" - 14

10шт.

3071405R1

BOLT,Hex, 7/16" - 14 x 1.50"

roll pin

2шт.

3071404R1

PIN

roll

2шт.

3070558R1

WASHER

10шт.

3071406R1

WASHER

roll pin bolt

2шт.

3071408R2

SHIM

heavy

1шт.

3071409R2

SHIM

medium

1шт.

3071410R2

SHIM

light

1шт.

3071411R2

SHIM

extra heavy

1шт.

3071416R91

PACKAGE, field improvement for machines equipped with 3068865R92

1шт.
