Запчасти Case IH 4240 (9-074) - CAB, WINDSHIELD WASH AND WIPE UNIT (09) - CHASSIS/ATTACHMENTS

116702A2

CAB

- complete with trim (With air conditioning)

1шт.

116773A1

CAB

- complete with trim (Without air conditioning), Includes: Ref. 1 - 9

1шт.

1

3401302R93

WIPER MOTOR

MOTOR - windshield wiper

1шт.

2

614-6012

BOLT,Hex, M6 x 1 x 12mm, Cl 8.8, Full Thd

3шт.

3

892-11006

LOCK WASHER,M6

WASHER, LOCK, M6

3шт.

4

3234718R1

LEVER

- wiper actuating

1шт.

5

892-11006

LOCK WASHER,M6

WASHER, LOCK, M6

1шт.

6

825-1406

NUT,M6, Cl 8

1шт.

7

3234391R1

LEVER

ARM - wiper actuating

1шт.

8

3234394R1

PIVOT

- wiper actuating

1шт.

9

3234750R1

PLUG

- blanking

1шт.

10

3234745R1

WIPER ARM

ARM - wiper

1шт.

11

829-1408

NUT,Hex, M8 x 1.25, Cl 10.9

- hex, 8 mm - 1.25, class 10

1шт.

12

892-11008

LOCK WASHER,8mm ID

WASHER, LOCK, M8

1шт.

13

3234746R91

WIPER BLADE

BLADE - wiper

1шт.

14

3129895R3

SUPPORT

BRACKET - washer bottle

1шт.

15

628-6012

BOLT,Hex, M6 x 12mm, Cl 10.9, Full Thd

- hex, full threads, 6 - 1.0 x 12 mm, class 10.9

2шт.

16

892-11006

LOCK WASHER,M6

WASHER, LOCK, M6

2шт.

17

895-10006

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

- flat, 6.6 x 12.5 x 1.6 mm

2шт.

18

3129898R1

CONTAINER

- windshield wash, Serial Range: -JJE0913677

1шт.

19

3399298R1

HOSE

- wash wipe

1шт.

20

3129899R92

JET

NOZZLE - washer, windshield

1шт.

21

189009A1

RESERVOIR

CONTAINER - windshield wash, Includes: Ref. 22 and 23, Start Serial: JJE0913678

1шт.

22

189014A1

PUMP

MOTOR - wash, Start Serial: JJE0913678

1шт.

23

189013A1

GROMMET

- washer container, Start Serial: JJE0913678

1шт.

24

188934A1

HARNESS

- wash motor, Start Serial: JJE0913678

1шт.
