Запчасти Case IH 4240 (8-06) - OIL COOLER SYSTEM, TRACTOR WITH CAB (08) - HYDRAULICS

1

218-5106

90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB

- 90 degree, 3/4-16 inch flare x Adj O-Ring boss

2шт.

2

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

8-1, 90 Duro, .644" ID x .087" Thk

2шт.

3

122355A2

HYD TUBE

TUBE ASSEMBLY - oil cooler return, rear (4210/4230)

1шт.

3

123788A1

HYD TUBE,0.5" OD, 1037, 166 mm Length

TUBE ASSEMBLY - oil cooler return, rear (4240)

1шт.

4

122353A1

HYD TUBE

TUBE ASSEMBLY - oil cooler supply, rear

1шт.

5

3125239R1

COLLAR

CLAMP - hose, worm drive

2шт.

6

1500540C1

HOSE

- lubrication

1шт.

8

1500148C1

CLAMP

- tube

1шт.

9

602836C1

CLAMP

- tube

1шт.

10

492-11038

LOCK WASHER,3/8"

1шт.

11

413-652

BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5

1шт.

12

122996A3

HYD TUBE,0.312 - 0.5" OD

TUBE ASSEMBLY - oil cooler return, front (4210/4230), Serial Range: -JJE922255

1шт.

12

238024A1

HYD TUBE,0.312 - 0.5" OD

TUBE ASSEMBLY - oil cooler return, front (4210/4230), Start Serial: JJE922256

1шт.

12

123791A2

HYD TUBE

TUBE ASSEMBLY - oil cooler supply, front (4240), Serial Range: -JJE922255

1шт.

12

238596A1

HYD TUBE,0.5-0.312" OD

TUBE ASSEMBLY - oil cooler supply, front (4240), Start Serial: JJE922256

1шт.

13

122997A2

HYD TUBE

TUBE ASSEMBLY - oil cooler supply, front (4210/4230), Serial Range: -JJE922255

1шт.

13

238025A1

HYD TUBE

TUBE ASSEMBLY - oil cooler supply, front (4210/4230), Start Serial: JJE922256

1шт.

13

138520A1

PIPE

TUBE ASSEMBLY - oil cooler return, front (4240), Serial Range: -JJE922255

1шт.

13

238595A1

HYD TUBE,0.5" OD

TUBE ASSEMBLY - oil cooler return, front (4240), Start Serial: JJE922256

1шт.

14

529644R11

CLAMP

- tube

1шт.

15

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

16

413-410

BOLT,Hex, 1/4" - 20 x 5/8", Gr 5

- hex, 1/4 NC x 5/8 inch

1шт.

16

413-422

BOLT,Hex, 1/4" - 20 x 1-3/8", Gr 5

- hex, 1/4 NC x 1-3/8 inch

1шт.

17

98937C1

SUPPORT

BRACKET ASSEMBLY - front, Serial Range: -JJE922255

1шт.

18

529644R11

CLAMP

- tube

1шт.

19

22-824

CABLE TIE,3/16" x 7 1/4"

STRAP - tie, 7 inch, cable

1шт.

20

NSS

NOT SOLD SEPARAT

HOSE - oil cooler, 940 mm (Order 3 x 3125980RX and, Serial Range: cut-length)

1шт.

3125980RX

LARGE HOSE

HOSE - hydraulic, 1/2 ID x 50 feet (Sold in 1 foot lengths)

1шт.

21

214-1410

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

CLAMP, HOSE, #10, 0.56/1.06 Type F Worm

4шт.

22

136842A1

COOLER, OIL

COOLER - oil, with air conditioning

1шт.

23

1536993C1

THUMB SCREW,Winged, 5/16" - 18 x 12.70mm

- thumb, 5/16 inch NC

4шт.

24

493-81008

LOCK WASHER,Int Tooth, 5/16"

WASHER - internal tooth lock, 5/16 inch

4шт.

25

495-11034

WASHER,5/16", SAE

5/16" SAE (flat, 11/32 x 11/16 x 1/16")

4шт.

26

673171C1

RUBBER BUSHING

SLEEVE - rubber, protector

1шт.

27

244418A1

SUPPORT

BRACKET - oil cooler pipes, Start Serial: JJE922256

1шт.
