Запчасти Case IH 4240 (8-04) - OIL COOLER SYSTEM, TRACTOR WITHOUT CAB (08) - HYDRAULICS
№
Артикул
Название
Примечание
Количество
1
218-5106
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
- 90 degree, 3/4-16 inch flare x Adj O-Ring boss, Includes: Ref. 2
2шт.
2
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
8-1, 90 Duro, .644" ID x .087" Thk
1шт.
3
123562A1
HYD TUBE
TUBE ASSEMBLY - oil cooler return, rear (2WD)
1шт.
3
127283A1
HYD TUBE
TUBE ASSEMBLY - oil cooler return, rear (MFD)
1шт.
4
3129259R2
PIPE
TUBE ASSEMBLY - oil cooler supply, rear
1шт.
5
138974A2
HYD TUBE,0.312 - 0.5" OD, 1240, 354 mm Length
TUBE ASSEMBLY - oil cooler return, front (4210/4230)
1шт.
5
138522A2
PIPE,0.5" OD, 1228, 251.6 mm Length
TUBE ASSEMBLY - oil cooler return, front (4240)
1шт.
6
138975A2
HYD TUBE,0.5" OD, 1362, 426 mm Length
TUBE ASSEMBLY - oil cooler, front (4210/4230)
1шт.
6
138521A1
PIPE
TUBE ASSEMBLY - oil cooler supply, front (4240)
1шт.
7
99790C1
SUPPORT
BRACKET - support
1шт.
8
892-11006
LOCK WASHER,M6
WASHER, LOCK, M6
4шт.
9
425-104
NUT,1/4"-20, Cl 5
- hex, 1/4 inch NC
1шт.
10
99788C1
CLAMP
- tube
1шт.
11
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
1шт.
12
614-6030
BOLT,Hex, M6 x 1 x 30mm, Cl 8.8, Full Thd
1шт.
13
529644R11
CLAMP
- tube
1шт.
14
413-410
BOLT,Hex, 1/4" - 20 x 5/8", Gr 5
- hex, 1/4 NC x 5/8 inch
2шт.
14
413-422
BOLT,Hex, 1/4" - 20 x 1-3/8", Gr 5
- hex, 1/4 NC x 1-3/8 inch
1шт.
15
529644R11
CLAMP
- tube
1шт.
16
98937C1
SUPPORT
BRACKET ASSEMBLY - front
1шт.
17
214-1410
HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm
CLAMP, HOSE, #10, 0.56/1.06 Type F Worm
4шт.
18
NSS
NOT SOLD SEPARAT
HOSE - oil cooler 580 mm (Order 2 x 3125980RX and, Serial Range: cut-length)
1шт.
19
NSS
NOT SOLD SEPARAT
HOSE - oil cooler 580 mm (Order 2 x 3125980RX and, Serial Range: cut-length)
1шт.
3125980RX
LARGE HOSE
HOSE - hydraulic, 1/2 ID x 50 feet (Sold in 1 foot lengths)
1шт.
20
136842A1
COOLER, OIL
COOLER - oil
1шт.
21
1537054C1
SUPPORT
BRACKET - support, (4240)
1шт.
Выбрано товаров: 26
