Запчасти Case IH 364 (6-38) - ATTACHMENTS, SINGLE SPEED CONSTANT RUNNING P.T.O. ATTACHMENT, SINGLE SPEED P.T.O. GEARS AND SHAFTS Attachments

1

751077R1

CAGE

bearing, trans, driving shaft

1шт.

2

751140R91

SEAL

OIL SEAL, P.T.O. driving shaft, rear, opt.

1шт.

2

3042160R91

SEAL

OIL SEAL, P.T.O. driving shaft, rear, opt.

1шт.

3

703911R1

RING

CIRCLIP, P.T.O. driving shaft rear bearing retaining, 110 mm int., opt.

1шт.

3

933078R1

SNAP RING,M110, Int

RING, locking, opt.

1шт.

4

3074379R1

SNAP RING

CIRCLIP, Anderton type 1400 60mm, opt.

1шт.

4

703696R1

RING

CIRCLIP, P.T.O. driving shaft rear brg retaining, 60 mm ext., opt.

1шт.

4

3064407R1

SNAP RING

CIRCLIP, P.T.O. driving shaft rear bearing retaining, 60 mm ext., opt.

1шт.

5

3069353R91

BALL BEARING

BEARING, P.T.O. driving shaft, rear, R & M

1шт.

5

3069352R91

BEARING, BALL

BEARING, P.T.O. driving shaft, rear, Fischer

1шт.

5

3069349R91

BEARING, BALL

BEARING, P.T.O. driving shaft, rear, S.K.F.

1шт.

5

3069355R91

BEARING, BALL

BEARING, P.T.O. driving shaft, rear, Hoffman

1шт.

6

3044006R1

GEAR

SHAFT, driving and gear, P.T.O., .5T

1шт.

Applicable for 573 rpm

1шт.

6

3044303R1

SHAFT

driving and gear, P.T.O., .9T

1шт.

Applicable for 783 rpm

1шт.

7

704235R91

BALL BEARING

BEARING, P.T.O. driving shaft, front, opt.

1шт.

7

704234R91

BALL BEARING

BEARING, P.T.O. driving shaft, front, opt.

1шт.

7

20181D

BEARING, P.T.O. driving shaft, front, opt.

1шт.

7

3048701R91

BALL BEARING

BEARING, P.T.O. driving shaft, front, opt.

1шт.

8

704229R91

OIL SEAL

P.T.O. driving shaft, front, opt.

1шт.

8

704230R90

OIL SEAL, P.T.O. driving shaft, front, opt.

1шт.

8

3066615R91

OIL SEAL,50mm ID x 80.15mm OD x 10mm Thk

OIL SEAL, P.T.O. driving shaft, front, opt.

1шт.

9

751149R1

RING

CIRCLIP, P.T.O. front bearing retaining, 85 mm int.

2шт.

10

751148R3

CAP

P.T.O. front bearing

1шт.

11

468335R1

O-RING,0.21" Thk x 3.25" ID, -340, Cl 5, 75 Duro

"O" RING, P.T.O. front bearing cap, 3-3/8" x 3-3/4" x 3/16"

1шт.

12

516010R1

O-RING

CIRCLIP, 3/4" ext.

1шт.

13

NSS

NOT SOLD SEPARAT

(Not used)

1шт.

14

751142R1

WASHER

retaining P.T.O. shaft front

1шт.

15

751146R1

RING

CIRCLIP, P.T.O. front bearing retaining, 45 mm ext.

1шт.

16

703644R91

BALL BEARING

BEARING, P.T.O. shaft, front, opt.

1шт.

16

42454H

BALL BEARING

BEARING, P.T.O. shaft, front, opt.

1шт.

17

751145R1

RING, SNAP

CIRCLIP, P.T.O. driven gear

1шт.

18

3044007R11

GEAR

w/circlip 751145R1, CPTE., driven P.T.O., 55T

1шт.

Applicable for 573 rpm

1шт.

18

3044302R11

GEAR

w/circlip 751145R1, CPTE., driven P.T.O., 51T

1шт.

Applicable for 783 rpm

1шт.

1026425R1

PRODUCT GRAPHIC

P.T.O.

1шт.

1026437R1

DECAL

PRODUCT GRAPHIC P.T.O.

1шт.
