Запчасти Case IH 354 (6-68) - ATTACHMENTS, GENERATOR ATTACHMENT Attachments

3072953R91

GENERATOR

CPTE., ventilated (Less Tacho drive - Lucas 22758) (Not serviceable), comprising:

1шт.

3109419R91

GENERATOR

CPTE., ventilated w/Tacho drive (Lucas 22756) (Service only), comprising:

1шт.

1

NSS

NOT SOLD SEPARAT

NUT, shaft

1шт.

Part of Sundry Parts, P/N 3114204R91

1шт.

2

NSS

NOT SOLD SEPARAT

WASHER, shakeproof 7/16"

1шт.

Part of Sundry Parts, P/N 3114204R91

1шт.

3

NSS

NOT SOLD SEPARAT

COLLAR, drive end bearing

1шт.

Part of Sundry Parts, P/N 3114204R91

1шт.

4

3073922R91

BRACKET

drive end, w/kit 3114206R91

1шт.

5

3073921R91

BEARING

drive end

1шт.

6

3114206R91

KIT

bearing retention w/plate and three rivets

1шт.

7

NSS

NOT SOLD SEPARAT

RETAINER, bearing

1шт.

Part of Sundry Parts, P/N 3114204R91

1шт.

8

3073924R91

ARMATURE

1шт.

9

NSS

NOT SOLD SEPARAT

RING, pressure

1шт.

Part of C.E. Kit, P/N 3114205R91

1шт.

10

3043338R91

COIL

S, field set

1шт.

11

3043339R91

TERMINAL CONNECTOR

KIT, terminal Lucas

1шт.

12

NSS

NOT SOLD SEPARAT

COLLAR, commutator end bearing

1шт.

Part of C.E. Kit, P/N 3114205R91

1шт.

13

3073916R91

BEARING

ball commutator end

1шт.

14

NSS

NOT SOLD SEPARAT

HOLDER, brush (Order 3114205R91)

2шт.

15

3114203R1

COVER, Tach blank off (Used w/Lucas gen. 22758)

1шт.

16

3073917R91

BRACKET

commutator w/kit 3114205R9

1шт.

17

702001R1

BOLT

through facing

2шт.

3073915R91

BRUSH, COMMUTATOR

SET, brush

1шт.

3114202R91

SET, brush tension spring (Used w/Lucas gen. 22758)

1шт.

3114204R91

KIT

PARTS, sundry, comprises items

1шт.

3114205R91

KIT, C.E. bracket bearing retention comprises items

1шт.

3073914R1

CLIP

bush (Used w/gen 22756) (Order kit 3114202R91)

1шт.

3107839R1

BUSHING, bearing (Used w/gen. 22756)

1шт.

179818

BOLT,Hex, 5/16" - 18 x 1", Gr 5

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.
