Запчасти Case IH 354 (6-63) - ATTACHMENTS, MOWER DRIVE ATTACHMENTS Attachments

NSS

NOT SOLD SEPARAT

ATTACHMENT, mower drive, for m/c's fitted with two speed C.R.P.T.O. attachment (Factory application)

1шт.

Units. Letters of these units correspond with those following the descripition of the parts in the list below and identifies the unit for which the part is used. Items without letters after the description indicates the part is used for all units, comprising: mower drive controls (See detail list), clutch housing (See detail list), mower drive gears and shafts (Single speed) (C.D.E.F.) (See detail list), mower drive gears and shafts (Two speed) (A.B.) (See detail list)

1шт.

3107744R92

ATTACHMENT, mower drive, for m/c's fitted with two speed C.R.P.T.O. attachment (Not serviced)

1шт.

Units. Letters of these units correspond with those following the descripition of the parts in the list below and identifies the unit for which the part is used. Items without letters after the description indicates the part is used for all units, comprising: mower drive controls (See detail list), clutch housing (See detail list), mower drive gears and shafts (Single speed) (C.D.E.F.) (See detail list), mower drive gears and shafts (Two speed) (A.B.) (See detail list)

1шт.

NSS

NOT SOLD SEPARAT

ATTACHMENT, mower drive, for m/c's fitted with 698 RPM single speed C.R.P.T.O. attachment (Factory application)

1шт.

Units. Letters of these units correspond with those following the descripition of the parts in the list below and identifies the unit for which the part is used. Items without letters after the description indicates the part is used for all units, comprising: mower drive controls (See detail list), clutch housing (See detail list), mower drive gears and shafts (Single speed) (C.D.E.F.) (See detail list), mower drive gears and shafts (Two speed) (A.B.) (See detail list)

1шт.

3107746R92

ATTACHMENT, mower drive, for m/c's fitted with 698 RPM single speed C.R.P.T.O. attachment (Not serviced)

1шт.

Units. Letters of these units correspond with those following the descripition of the parts in the list below and identifies the unit for which the part is used. Items without letters after the description indicates the part is used for all units, comprising: mower drive controls (See detail list), clutch housing (See detail list), mower drive gears and shafts (Single speed) (C.D.E.F.) (See detail list), mower drive gears and shafts (Two speed) (A.B.) (See detail list)

1шт.

NSS

NOT SOLD SEPARAT

ATTACHMENT, mower drive, for m/c's fitted with 550 RPM single speed C.R.P.T.O. attachment (Factory application)

1шт.

Units. Letters of these units correspond with those following the descripition of the parts in the list below and identifies the unit for which the part is used. Items without letters after the description indicates the part is used for all units, comprising: mower drive controls (See detail list), clutch housing (See detail list), mower drive gears and shafts (Single speed) (C.D.E.F.) (See detail list), mower drive gears and shafts (Two speed) (A.B.) (See detail list)

1шт.

3107748R92

ATTACHMENT, mower drive, for m/c's fitted with 550 RPM C.R.P.T.O. attachment (Not serviced)

1шт.

Units. Letters of these units correspond with those following the descripition of the parts in the list below and identifies the unit for which the part is used. Items without letters after the description indicates the part is used for all units, comprising: mower drive controls (See detail list), clutch housing (See detail list), mower drive gears and shafts (Single speed) (C.D.E.F.) (See detail list), mower drive gears and shafts (Two speed) (A.B.) (See detail list)

1шт.

1

3064430R1

COVER

P.T.O. bottom, mower drive controls

1шт.

2

3049108R2

SHAFT

high low range shifter, mower drive controls

1шт.

3

3049109R1

HANDLE

high low range shifter, mower drive controls

1шт.

142358

PIN

groove type 1/4" x 1-1/2", mower drive controls

1шт.

4

3048748R4

LEVER

forward and reverse, mower drive controls

1шт.

5

53717DA

BUTTON

BALL, gear shifter lever, mower drive controls

1шт.

6

3049105R1

RETAINER

CIRCLIP, Anderton, mower drive controls

1шт.

7

3114105R91

ROD

control CPTE., comprising:, mower drive controls

1шт.

8

104038

ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"

CLEVIS, adj. rod end, mower drive controls

2шт.

9

114494

NUT,Jam, 3/8"-24, G5

Mower drive controls Jam, 3/8"-24, G5

2шт.

10

3114108R1

ROD, control, mower drive controls

1шт.

107762

WASHER,3/32" x 5/8"

PIN, SPLIT, (COTTER), , Mower drive controls 3/32" x 5/8"

2шт.

NLS

NO LONGER SERVICED

PIN, 3/8" x 1-3/32" rod end, mower drive controls

2шт.

11

3071367R1

LEVER

operating fork, mower drive controls

1шт.

179821

BOLT,Hex, 5/16" - 18 x 1 3/8", Gr 5

Mower drive controls Hex, 5/16"-18 x 1 3/8", G5

1шт.

9635082

NUT,5/16" - 18, Gr 5

hex 5/16, mower drive controls

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, , Mower drive controls 5/16"

1шт.

12

3064426R91

BRACKET, operating fork cpte., mower drive controls

1шт.

179841

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

hex hd. 3/8"-16 x 1-1/4", Mower drive controls

2шт.

13

3065499R91

FORK

w/pin 17175R1 operating and shaft assy., mower drive controls

1шт.

17175R1

LOCK PIN,3/16" x 1", Slotted

PIN, , Mower drive controls 3/16" x 1", Slotted

2шт.
