Запчасти Case IH 354 (6-26) - ATTACHMENTS, SINGLE SPEED P.T.O. GEARS AND SHAFTS, CONSTANT RUNNING P.T.O. ATTACHMENT Attachments

1

751077R1

CAGE

bearing, trans. driving shaft

1шт.

2

751140R91

SEAL

OIL SEAL, P.T.O. driving shaft, rear, Opt.

1шт.

2

3042160R91

SEAL

OIL SEAL, P.T.O. driving shaft, rear, Opt.

1шт.

3

703911R1

RING

CIRCLIP, P.T.O. driving shaft rear bearing retaining (110 mm internal), Opt.

1шт.

3

933078R1

SNAP RING,M110, Int

RING, locking, Opt.

1шт.

4

3064407R1

SNAP RING

CIRCLIP, P.T.O. driving shaft rear bearing retainer, Opt.

1шт.

4

703696R1

RING

CIRCLIP, P.T.O. driving shaft rear bearing retaining (60 mm external), Opt.

1шт.

4

3074379R1

SNAP RING

CIRCLIP, Anderton type 1400 60 mm., Opt

1шт.

5

ST269A

BALL BEARING,60mm ID x 110mm OD x 22mm W

BEARING, P.T.O. driving shaft, rear (I.H.), Opt.

1шт.

5

3069353R91

BALL BEARING

BEARING, P.T.O. driving shaft, rear, (R & M), Opt.

1шт.

5

3069352R91

BEARING, BALL

BEARING, P.T.O. driving shaft, rear, (Fischer), Opt.

1шт.

5

3069349R91

BEARING, BALL

BEARING, P.T.O. driving shaft, rear, (S.K.F.), Opt.

1шт.

5

3069355R91

BEARING, BALL

BEARING, P.T.O. driving shaft, rear, (Hoffman), Opt.

1шт.

6

751137R1

SHAFT, driving and gear, P.T.O. (16 teeth)

1шт.

Applicable for 555 R.P.M.

1шт.

6

3044303R1

SHAFT

driving and gear, P.T.O.

1шт.

Applicable for 698 R.P.M.

1шт.

7

704234R91

BALL BEARING

BEARING, P.T.O. driving shaft, front, Opt.

1шт.

7

20161D

BEARING, BALL,50 mm ID x 90 mm OD x 20 mm

BEARING, P.T.O. driving shaft, front, Opt.

1шт.

8

704229R91

OIL SEAL

P.T.O. driving shaft, front, Opt.

1шт.

8

704230R91

SEAL

OIL SEAL, P.T.O. driving shaft, front, Opt.

1шт.

8

3066615R91

OIL SEAL,50mm ID x 80.15mm OD x 10mm Thk

OIL SEAL, P.T.O. driving shaft, front, Opt.

1шт.

9

751149R1

RING

CIRCLIP, P.T.O. front bearing retaining (85 mm internal)

2шт.

10

751148R3

CAP

P.T.O. front bearing

1шт.

11

751147R1

O-RING

P.T.O. front bearing cap

1шт.

12

516010R1

O-RING

CIRCLIP, 3/4" external

1шт.

13

NSS

NOT SOLD SEPARAT

(Not used)

1шт.

14

751142R1

WASHER

retaining P.T.O. shaft, front

1шт.

15

751146R1

RING

CIRCLIP, P.T.O. front bearing retaining (45 mm external)

1шт.

16

704327R91

BEARING, BALL

BEARING, PTO shaft front, Opt.

1шт.

16

703644R91

BALL BEARING

BEARING, PTO shaft front, Opt.

1шт.

16

42454H

BALL BEARING

BEARING, PTO shaft front, Opt.

1шт.

16

3114943R91

BEARING

PTO shaft front (NTN), Opt.

1шт.

17

751145R1

RING, SNAP

CIRCLIP, P.T.O. driven gear

1шт.

18

3044302R11

GEAR

driven, P.T.O. (51 teeth) CPTE., w/circlip, 751145R1

1шт.

Applicable for 698 R.P.M.

1шт.

18

751144R11

GEAR, driven, P.T.O. (54 teeth) CPTE., w/circlip 751145R1

1шт.

Applicable for 555 R.P.M.

1шт.
