Запчасти Case IH 350 (292) - HYDRAULIC SYSTEM, HYDRAULIC EQUIPMENT, SPECIAL (07) - HYDRAULIC SYSTEM

362029R91

ADAPTER, cylinder hose attaching, w/nut

1шт.

364061R91

ADAPTER, cylinder hose attaching, w/nut

1шт.

366064R1

CONNECTOR, ELEC

ADAPTER, union (7/8-14 male thread x 1/2" female NPT) (For Allied Equipment)

1шт.

368086R91

CONNECTOR, ELEC

ADAPTER, union (For connecting test gauge to regulator safety and flow control valve)

1шт.

361889R21

BRACKET, hydraulic cylinder, w/two pins, 364256R1

1шт.

364257R1

BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 8

SCREW, hydraulic cylinder bracket

1шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

1шт.

365405R11

BRACKET, break-away coupling, w/pin

1шт.

271557

DEFLECTOR,Hex, 5/8" - 11 x 1 3/8", Gr 5

SCREW, cap, hex-hd., 5/8-11NC x 1-3/8"

1шт.

103325

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

368710R1

CAP

dust hydraulic self-sealing and break-away coupling (Will work for 355190R1 and 364655R1)

1шт.

353216R91

COUPLING

break-away rear section, assembly (For components see list of parts under details of "Break-Away And Self-Sealing Couplings")

1шт.

364311R91

COUPLING, break-away front section, assembly (For components see list of parts under details of "Break-Away And Self-Sealing Couplings")

1шт.

103385

COTTER PIN,1/8" x 1"

PIN, SPLIT (COTTER), 1/8" x 1"

1шт.

360994R91

CYLINDER

hydraulic (2-1/2 x 8"), assembly (For components see list of parts under details of "Hydraulic Cylinders")

1шт.

360997R91

CYLINDER, hydraulic (3-1/2 x 8"), assembly (For components see list of parts under details of "Hydraulic Cylinders")

1шт.

363628R1

ELBOW, street, cylinder hose

1шт.

364148R1

ELBOW

street, cylinder hose

1шт.

444496

ELBOW, street, cylinder hose

1шт.

362784R91

HOSE

hydraulic cylinder, 1/2" x 112"

1шт.

363715R91

HOSE

hydraulic cylinder, 1/2" ID x 22"

1шт.

363716R91

HOSE, hydraulic cylinder, 1/2" ID x 29-1/2"

1шт.

355565R92

HOSE

valve front port to LH side of the break-away coupling, 1/2" ID x 40-1/2" long

1шт.

365399R92

HOSE, valve front port to LH side of the break-away coupling, 1/2" ID x 31" long

1шт.

355543R91

HOSE

valve rear port to RH side of the break-away coupling, 1/2" ID x 37-1/2" long

1шт.

355584R91

HOSE, valve rear port to RH side of the break-away coupling, 1/2" x 28" long

1шт.

192050

NIPPLE, LUBE,Nipple, 1/4" NPT x 7/8"

NIPPLE, pipe, close, cd-pltd., 1/4 x 7/8"

1шт.

192053

NIPPLE, pipe, long, cd-pltd., 1/2 x 2"

1шт.

192074

NIPPLE, LUBE,Nipple, 1/2" NPT x 1 1/8"

NIPPLE, pipe, close, cd-pltd., 1/2 x 1-1/8"

1шт.

192077

NIPPLE, pipe, long, cd-pltd., 1/2 x 2-1/2"

1шт.

253070R1

O-RING,0.139" Thk x 0.859" ID, -212, Cl 5, 75 Duro

RING, seal, check valve (Will work for 352024R2)

1шт.

369413R91

PACKAGE, hydra-touch valve o-ring back-up washer (Consists of 50 washers)

1шт.

353213R2

SPRING

break-away coupling bracket

1шт.

363452R91

VALVE

check, assembly (For components see list of parts under details of "Check Valve")

1шт.

179847

BOLT,Hex, 3/8" - 16 x 2", Gr 5

1шт.

19849H

WASHER, plain, 33/64" ID x 1-3/8" OD x No. 11 ga.

1шт.
