Запчасти Case IH 3230 (8-004) - OIL COOLER SYSTEM, TRACTOR WITHOUT CAB (08) - HYDRAULICS

1

218-5106

90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB

90 degree, 3/4-16 inch flare x adj o-ring boss

2шт.

2

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

8-1, 90 Duro, .644" ID x .087" Thk

2шт.

3

123562A1

HYD TUBE

TUBE ASSEMBLY oil cooler return, rear, 2WD

1шт.

3

127283A1

HYD TUBE

TUBE ASSEMBLY oil cooler return, rear, MFD

1шт.

4

3129259R2

PIPE

TUBE ASSEMBLY oil cooler supply, rear

1шт.

5

138240A1

PIPE

TUBE ASSEMBLY oil cooler return, front, 3220

1шт.

5

138974A2

HYD TUBE,0.312 - 0.5" OD, 1240, 354 mm Length

TUBE ASSEMBLY oil cooler return, front, 3230

1шт.

6

138239A1

PIPE

TUBE ASSY. oil cooler supply, front, 3220

1шт.

6

138975A2

HYD TUBE,0.5" OD, 1362, 426 mm Length

TUBE ASSEMBLY oil cooler, front, 3230

1шт.

7

99790C1

SUPPORT

BRACKET support

1шт.

8

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

4шт.

9

425-104

NUT,1/4"-20, Cl 5

hex, 1/4 inch NC

1шт.

10

99788C1

CLAMP

tube

1шт.

11

892-11006

LOCK WASHER,M6

WASHER, LOCK, M6

1шт.

12

614-6030

BOLT,Hex, M6 x 1 x 30mm, Cl 8.8, Full Thd

1шт.

13

529644R11

CLAMP

tube

1шт.

14

413-410

BOLT,Hex, 1/4" - 20 x 5/8", Gr 5

hex, 1/4 NC x 5/8 inch

3шт.

15

529644R11

CLAMP

tube

1шт.

16

98937C1

SUPPORT

BRACKET ASSEMBLY front

1шт.

17

214-1410

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

CLAMP, HOSE, #10, 0.56/1.06 Type F Worm

4шт.

18

NSS

NOT SOLD SEPARAT

HOSE oil cooler 580 mm, Order 2 x 3125980RX and, Serial Range: cut-length

1шт.

19

NSS

NOT SOLD SEPARAT

HOSE oil cooler 580 mm, Order 2 x 3125980RX and, Serial Range: cut-length

1шт.

3125980RX

LARGE HOSE

HOSE hydraulic, 1/2 ID x 50 feet, sold in 1 foot lengths

1шт.

20

136841A1

COOLER, OIL

COOLER oil, stud mounted

1шт.
