Запчасти Case IH 284 (12-32) - POWER, GASOLINE ENGINE, MAZDA, GOVERNOR AND CONNECTIONS Power

1

1014280C92

GOVERNOR

ASSY, for components see list of parts under details of governor

1шт.

2

1014281C1

BRACKET

governor

1шт.

3

1014306C1

SPACER

1шт.

4

1014286C1

ROD

1шт.

5

IDLER ASSY, order component parts

1шт.

6

1014307C2

PULLEY

1шт.

7

1014283C1

BRACKET, governor

1шт.

8

1014350C1

BOLT

adjust

1шт.

9

1014287C1

SHAFT

idler

1шт.

10

1014049C1

BOLT

SET

1шт.

11

1014050C1

SPACER

1шт.

12

1014051C1

BALL BEARING

BEARING, ball

1шт.

13

1014052C1

SEAL

dust

2шт.

14

1014401C1

RING

snap

1шт.

15

WASHER, spring, purchase locally

1шт.

16

1014412C1

BOLT, set

2шт.

17

1014413C1

BOLT, 20mm long

3шт.

17

1004595C1

BOLT, 30mm long

1шт.

18

1014440C1

NUT

3шт.

19

1014439C1

NUT

3шт.

1004521C1

WASHER, spring

3шт.

20

COVER, order cover 1004811C2

1шт.

21

BRACKET, order cover 1004811C2

1шт.

22

30191R1

BOLT,Hex, M6 x 1 x 12mm, Cl 10.9, Full Thd

M6 x 12 PHC class 10.9

2шт.

23

978085C1

WASHER

M6 x M11.5 x M0.8

2шт.

24

1004811C2

SHIELD

COVER, safety RH, replaces cover, 1002839C2 and bracket, 1002840C2

1шт.
