Запчасти Case IH 2806 (M-07[A]) - SEAT, OPERATORS PLATFORM & MISCELLANEOUS, FRONT END WEIGHT BRACKET AND WEIGHTS (10) - OPERATORS PLATFORM

383388R91

PARTS ACCESSORY, front end weight mounting bracket, also order weight and mounting parts desired, Farmall tractors with serial no. 33162 and below, International tractors with serial no. 7100 and below, unit A

1шт.

394446R91

PARTS ACCESSORY, front end weight mounting bracket, also order weight and mounting parts desired, Farmall tractors with serial no. 33163 and above, International tractors with serial no. 7101 and above, unit B

1шт.

1

383389R11

BRACKET

ASSEMBLY, front weight, unit A

1шт.

1

394447R11

BRACKET ASSY, front weight, unit B

1шт.

21452R1

BOLT,Hex, 3/4" - 10 x 2", Gr 8

SCREW, 3/4-10 x 2 znd hex-hd cap type 4

4шт.

103326

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

2шт.

369857R1

WASHER,20.7mm ID x 31.75mm OD x 3mm Thk

25/32 x 1-1/4 x 11 ga

2шт.

2

383392R1

WEIGHT

front end, 67 lbs

1шт.

2

383393R1

WEIGHT

front end, 100 lbs

1шт.

105608

NUT

1/2-13 sq

1шт.

179897

BOLT,Hex, 1/2" - 13 x 4", Gr 5

SCREW, 1/2-13 x 4 hex-hd cap

1шт.
