Запчасти Case IH 276 (6-56) - NON VENTILATED GENERATOR ATTACHMENT, PETROL (04) - ELECTRICAL SYSTEMS

ATTACHMENT, generator non to, Serial Range: non-nondto

1шт.

3071631R91

ATTACHMENT, generator non to, Serial Range: non-nondto

1шт.

Letters of these units correspondto

1шт.

3063505R12

BRACKET, assy., generator

1шт.

Can only be used on machines fitted with Three Point Linkage Attachment 741938R92

1шт.

3064136R91

BRACKET

assy., (commutator end)lto

1шт.

3064137R91

BRACKET

assy., (drive end) (B)

1шт.

700468R1

BEARING

(drive end) (B)

1шт.

700474R1

BUSHING

BUSH, (commutator end) (B)

1шт.

707539R1

BRAKE, generator

1шт.

3043329R91

OILER

FELT, oiler (B)

1шт.

3049871R91

GENERATOR

cpte., (A) (see detailto

1шт.

3043333R1

PLATE

bearing (B)

1шт.

704448R1

PULLEY

generator

1шт.

3067851R91

REGULATOR

1шт.

3043340R91

PACKAGE

SET, sundry parts

1шт.

Part No.

EnglishENT, generator non to, Serial Range: non-nondto

1шт.

Can only be used on machines fitted with Three Point Linkage Attachment 741938R92

1шт.

3071632R91

ATTACHMENT, generator non to nondto, NON VENTILATED GENERATOR ATTACHMENT (DIESEL)

1шт.

3063506R12

BRACKET

assy., generatoro, NON VENTILATED ATTACHMENT (DIESEL)

1шт.

Can only be used on machines fitted with Three Point Linkage Attachment 741938R92

1шт.

3064138R91

ARMATURE

BRACKET, assy., (commutator end)lHoo, NON VENTILATED GENERATOR ATTACHMENT (DIESEL)

1шт.

3064137R91

BRACKET

assy., (drive end) (B)o, NON VENTILATED GENERATOR ATTACHMENT (DIESEL)

1шт.

700468R1

BEARING

(drive end) (B)o, NON VENTILATED GENERATOR ATTACHMENT (DIESEL)

1шт.

700474R1

BUSHING

BUSH, (commutator end) (B)o, NON VENTILATED GENERATOR ATTACHMENT (DIESEL)

1шт.

707539R1

BRACE, generatoro, NON VENTILATED ATTACHMENT (DIESEL)

1шт.

3043329R91

OILER

FELT, oiler (B)o, NON VENTILATED GENERATOR ATTACHMENT (DIESEL)

1шт.

3049871R91

GENERATOR

cpte., (A) (see detailHoo, NON VENTILATED ATTACHMENT (DIESEL)

1шт.

3043333R1

PLATE

bearing (B)o, NON VENTILATED GENERATOR ATTACHMENT (DIESEL)

1шт.

704448R1

PULLEY

generatoro, NON VENTILATED ATTACHMENT (DIESEL)

1шт.

Part No.

English

1шт.

On orders for 3071351R91 furnish 3071351R92 together w/SWITCH 3109707R91, 2 off FUSE HOLDER 3110004R91, 2 off FUSE 700166R1, or 707887R1, and SHROUD 3110000R91

1шт.

3071351R91

ATTACHMENT, cold starting,E (seeCHo

1шт.

On orders for 3071351R91 furnish 3071351R92 together w/SWITCH 3109707R91, 2 off FUSE HOLDER 3110004R91, 2 off FUSE 700166R1, or 707887R1, and SHROUD 3110000R91

1шт.

Part No.

English

1шт.

On orders for 3071351R91 furnish 3071351R92 together w/SWITCH 3109707R91, 2 off FUSE HOLDER 3110004R91, 2 off FUSE 700166R1, or 707887R1, and SHROUD 3110000R91

1шт.

3066743R91

SWITCH

solenoid starter , COMPONENTS

1шт.

110633

NUT,#10-24

sq-hd., No.10 - 24, Components

2шт.

110500

SCREW,Slotted Rd Hd, #10-24 x 1/2"

rd-hd., No.10 - 24 x 1/2" , COMPONENTS

2шт.

106497

LOCK WASHER,#10

WASHER, LOCK, , Components #10

2шт.

3062302R91

BREAKER

circuit , COMPONENTS

1шт.

426915

RETAINER

COMPONENTS

1шт.

436714

COMPONENTS

1шт.

121841

LOCK WASHER,#8

WASHER, LOCK, , Components #8

2шт.

3066551R1

BOLT

battery hold down , COMPONENTS

1шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, , Components 1/4"

1шт.

3071352R91

CABLE, battery to starter , COMPONENTS

1шт.

3066558R1

ELEMENT

ballast resistor (.040TCHo , COMPONENTS

1шт.

3110189R92

HARNESS, main cable, used w/SWITCHo , COMPONENTS

1шт.

3071353R91

ARMATURE

HARNESS, main cable, used w/SWITCHo , COMPONENTS

1шт.

3071353R91

ARMATURE

HARNESS, main cable , COMPONENTS

1шт.

703899R1

SPRING

WIRE, connecting No. 2 to No. 3g to , COMPONENTS

1шт.

3065071R2

FASTENER

WIRE, connecting No. 1 glow plug to , COMPONENTS

1шт.

703898R1

ELECTRICAL WIRE

WIRE, connecting No. 1 to No. 2 and , COMPONENTS

1шт.
