Запчасти Case IH 276 (6-50) - TWIN FUEL FILTER ATTACHMENT (03) - FUEL SYSTEM

3064796R91

1шт.

1

3064796R91

PIPE, fuel - excess fuel, cpte.,nj.

1шт.

2

3064790R91

PIPE

fuel - cpte., (filter in inj.

1шт.

3

708296R1

CONNECTOR, ELEC

BOLT, banjo, fuel filter

2шт.

4

708297R1

GASKET

WASHER, fuel filter banjo bolt

6шт.

5

3048142R91

NO LONGER SERVICED

FILTER, fuel, cpte., twin bowl-less

1шт.

179841

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

hex hd. 3/8"-16 x 1-1/4"

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

6

3064789R92

PIPE

fuel, cpte., (feed pump toohe

1шт.

7

3043646R1

VALVE, ball check assy.

1шт.

3049111R1

SEALING WASHER

1шт.

8

701735R1

WASHER

2шт.

9

3043647R1

CAPSCREW

SCREW, connection

1шт.

10

3064792R91

PIPE

fuel - (filter air bleed tohe

1шт.

11

3043655R1

CLIP

fuel pipe

1шт.

179793

BOLT,Hex, 1/4" - 20 x 5/8", Gr 5, Full Thd

1шт.

109084

NUT,1/4"-20, G5

1шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

3064788R1

BOLT,1/2" - 20 x 0.875", Brass

banjo, fuel filter (inlet)

1шт.
