Запчасти Case IH 276 (6-60A) - HEAVY DUTY BACK END ATTACHMENT (88) - ACCESSORIES

3107102R91

ATTACHMENT, heavy duty back end

1шт.

3110729R1

AXLE

rear

2шт.

3069356R91

BEARING, BALL

rear axle (opt.)

2шт.

3069357R91

BEARING, BALL

rear axle (opt.)

2шт.

3069358R91

BEARING

ball, rear axle (opt.)

2шт.

3069359R91

BEARING, BALL

rear axle (opt.)

2шт.

3106877R91

BEARING

ball, rear axle (opt.)

2шт.

3047576R2

BOLT

rear wheel hub

16шт.

3073799R91

BOX

CASE, trans. cpte., comprising

1шт.

3072136R1

BUSHING

BUSH, reverse idler gear, front

1шт.

711272R2

BUSHING

BUSH, reverse idler gear, rear

1шт.

332040

LUBE NIPPLE,90 Degree, 1/8" NPT x .84" lg

FITTING, lubrication 1/8" x 90 degrees

2шт.

141284

PIN,25.4mm OD x 31.75mm L

Pin 1/2" x 1 1/8"

2шт.

438159

DRAIN PLUG,Sq Hd, 1/2"-14 NPTF

PLUG, sq-hd., pipe, 1/2" (opt.)

3шт.

217-519

DRAIN PLUG,Sq Hd, 1/2"-14 NPTF

PLUG, , Pipe - Optional Sq Hd, 1/2"-14 NPTF

3шт.

172575

PLUG,Exp, 1 9/16"

1-9/16"

1шт.

701067R1

RING

CIRCLIP, (130 mm)

2шт.

3043995R1

COLLAR

rear axle

2шт.

709109R1

GASKET

rear axle bearing container

2шт.

709110R11

RETAINER

rear axle bearing, cpte., w/ OIL SEAL 703916R91

2шт.

179827

FRONT AXLE

8шт.

703916R91

SEAL

OIL SEAL (opt.)

1шт.

703917R92

OIL SEAL

OIL SEAL (opt.)

1шт.

3069937R91

SEAL

OIL SEAL (opt.)

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

8шт.

703915R1

WASHER,2.56mm ID x 3.13mm OD x 0.25mm Thk

felt, rear axle

1шт.

3074046R1

CARRIER, rear axle L.H.

1шт.

3074047R1

CARRIER, rear axle R.H.

1шт.

179886

BOLT,Hex, 1/2" - 13 x 1 5/8", Gr 5

hex-hd., 1/2" x 1-5/8"

20шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

20шт.

3071093R91

SEAT, FRITZMIER assy., w/Baseplate less Cushion, special parts attachment

1шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

hex-hd., 3/8" x 1", special parts attachment

2шт.

180179

BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 5

hex-hd., 1/2" x 1-3/4", special parts attachment

2шт.

3065389R1

NUT, Philidas lock, 1/2", special parts attachment

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, , Special parts attachment 3/8"

2шт.

495-11053

WASHER,1/2", SAE

flat, 17/32" x 1-1/16" x .095, special parts attachment

2шт.
