Запчасти Case IH 276 (8-02A) - PRODUCT GRAPHICS (09) - CHASSIS

1080357R1

DECAL

PRODUCT GRAPHIC, Model Designation

2шт.

2752873R1

PRODUCT GRAPHIC

"International"

2шт.

SAFETY FEATURES

1шт.

ATTACHMENT, safety features, factory application, (DOMESTIC)

1шт.

For 276 Industrial, fitted as basic equipment on domestic machines.

1шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, , PTF (For Safety features) (Domestic) 1/8"-27 x .66 lg

1шт.

179837

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

Fender, Safety features (Domestic) Hex, 3/8"-16 x 3/4", G5, Full Thd

1шт.

NLS

NO LONGER SERVICED

(Attaching, Safety Features (Domestic) Hex, 3/8"-16 x 1", G5

1шт.

102635

NUT,3/8"-16, G5

Safety Features (Domestic) 3/8"-16, G5

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, , Safety features (Domestic) 3/8"

2шт.

3070589R1

FOOTSTEP, SAFETY FEATURES (DOMESTIC)

1шт.

179839

BOLT,Hex, 3/8" - 16 x 1", Gr 5

Safety Features (Domestic) Hex, 3/8"-16 x 1", G5

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, , Safety features (Domestic) 3/8"

1шт.

HAND OPERATED DRUM BREAK ATTACHMENT

1шт.

ATTACHMENT, hand operated drum brake, factory application, comprising next 4 items

1шт.

Cannot be fitted to machines already fitted with heavy duty Back End Attachment

1шт.

BRAKE PEDAL AND SHAFT, see detail list , HAND OPERATED DRUM ATTACHMENT

1шт.

HAND BRAKE LINKAGE, see detail list , OPERATED DRUM ATTACHMENT

1шт.

DAFC DRUM BRAKE ASSY., 14" x 2", see detail list , OPERATED DRUM ATTACHMENT

1шт.

REAR AXLE AND CARRIERS, see detail list , HAND OPERATED DRUM BRAKE ATTACHMENT

1шт.
