Запчасти Case IH 276 (6-36) - BOSTROM SUSPENSION SEAT ATTACHMENT (09) - CHASSIS

Схема запчастей Case IH 276 - (6-36) - BOSTROM SUSPENSION SEAT ATTACHMENT (09) - CHASSIS
2
1

Артикул

Название

Примечание

Количество

ATTACHMENT, Bostrom Suspension Seat (Factory application) (A)

1шт.

3074216R91

1шт.

ATTACHMENT, Bostrom Suspension Seat (B) Units. Letters of these units correspond with those following the description of the parts in the list below and identifies the unit for which the part is used. Items without letters after the description indicates the part is used for all units.

1шт.

1

3070782R1

HOUSING

hyd. lift (A)

1шт.

2

3070785R91

PLATE, cpte., reg. number

1шт.

3071675R91

CABLE, reg. number plate flying lead

1шт.

705896R1

CONNECTOR, ELEC

CONNECTOR, 2 way

2шт.

705548R1

GROMMET

cover terminal

1шт.

3070784R92

SUSPENSION

SEAT, suspension (see detail list)

1шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8" x 1" hex-hd.

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

705545R1

TERMINAL, cover

1шт.

706102R1

SCREW, 3/16" x 5/8" rd-hd., sltd.

1шт.

114603

WASHER,Ext Tooth, #10

No. 10 lock

1шт.

Выбрано товаров: 14
