Запчасти Case IH 276 (6-45) - REAR WHEEL ATTACHMENT (06) - POWER TRAIN

3069491R92

ATTACHMENT, rear wheel (10-32)

1шт.

3049758R92

WHEEL ASSY

WHEEL, cpte., rear, rim & disc (10-32), each comprising

2шт.

3073908R1

BOLT

8шт.

3073907R1

DISC

1шт.

3073909R1

NUT

8шт.

3073906R91

RIM

1шт.

NLS

NO LONGER SERVICED

1шт.

3073908R1

BOLT

rear wheel disc

16шт.

3073907R1

DISC

rear wheel

2шт.

3073909R1

NUT

hex., 5/8" UNF

2шт.

3073906R91

RIM

assy., w/LUGS, rear wheel

2шт.

131016

WASHER

21/32" x 1-5/16" x .074"

2шт.

3040876R91

ATTACHMENT, assy., wheel,special, rear W9 x 28 (power adjusted)

1шт.

3040877R91

WHEEL, rear assy., special W9 x 28 (power adjusted), comprising

2шт.

3062565R1

BODY, stop, power adjusted

4шт.

3062563R1

BOLT, power adjusted

16шт.

3062557R1

BRACKET, disc to rail, power adjusted

8шт.

3062564R1

DISC, power adjusted

2шт.

3062562R1

NUT, power adjusted

16шт.

3062558R1

PIN, eccentric, power adjusted

8шт.

3062560R1

PIN, eccentric block, power adjusted

8шт.

3062556R91

RIM and RAIL, assy., power adjusted

2шт.

3062559R1

RING, snap, power adjusted

8шт.

3062566R1

SCREW, rim, stop, power adjusted

4шт.

3062561R1

WASHER, spring, power adjusted

8шт.

3069487R91

ATTACHMENT, rear wheel, tyre and tube 12 -24 (Agricultural), comprising

1шт.

3049216R91

RIM

and DISC, rear wheel, W12-24, comprising, tyre and tube

2шт.

703929R1

BOLT,5/8" - 18 x 2 7/8"

rear wheel rim, tyre and tube

12шт.

3061824R1

DISC

rear wheel (Agricultural), tyre and tube

2шт.

703930R2

NUT

rear wheel rim bolt, tyre and tube

12шт.

3061823R91

RIM

rear wheel, tyre and tube

2шт.

703931R1

WASHER

rear wheel rim bolt, tyre and tube

12шт.
