Запчасти Case IH 276 (6-24) - TRANSMISSION GEARS AND SHAFTS, CONSTANT RUNNING P.T.O. ATTACHMENT (06) - POWER TRAIN

1

751150R1

RETAINER

front bearing, trans. countershaft

1шт.

179840

BOLT,Hex, 3/8" - 16 x 1 1/8", Gr 5

hex-hd., 3/8" x 1-1/8"

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

2

751065R1

BEARING LOCK NUT

lock, countershaft front bearing

1шт.

3

751066R1

WASHER

lock, countershaft front bearing

1шт.

4

3068451R1

FRONT PTO ASSY

SHAFT, P.T.O. front

1шт.

5

751160R11

GEAR

COUNTERSHAFT, trans. and first speed gear, cpte. w/BUSH 751161R1

1шт.

6

751063R91

BALL BEARING,50 mm ID x 80 mm OD x 19 mm

ball, trans. countershaft, rear (R&M) (opt.)

1шт.

6

3040830R91

BALL BEARING

BEARING, ball, trans. countershaft, rear (Fischer) (opt.)

1шт.

6

3049757R91

BALL BEARING

BEARING, ball, trans. countershaft rear (opt.)

1шт.

7

751638R1

RING, SNAP

CIRCLIP, trans. countershaft rear bearing retaining

1шт.

751161R1

BUSHING

BUSH P.T.O. shaft

1шт.
