1
3071401R11
CAGE
bearing, bull pinion shaft, L.H. cpte., w/OIL SEAL 703908R92
1шт.
3071403R1
BOLT,Hex, 7/16" - 14
bull pinion bearing cage roll pin
5шт.
3071405R1
BOLT,Hex, 7/16" - 14 x 1.50"
roll pin
1шт.
3071404R1
PIN
roll
1шт.
3071406R1
WASHER
roll pin bolt
1шт.
3070558R1
WASHER
bull pinion shaft bearing cage
5шт.
2
3071410R2
SHIM
bull pinion bearing cage (light)
1шт.
2
3071409R2
SHIM
bull pinion bearing cage (medium)
1шт.
2
3071408R2
SHIM
bull pinion bearing cage (heavy)
1шт.
2
3071411R2
SHIM
bull pinion bearing cage (extra heavy)
1шт.
3
3043788R91
SEAL
OIL SEAL, bull pinion shaft (opt.)
2шт.
3
703908R92
OIL SEAL
bull pinion shaft (opt.)
2шт.
4
49533H
BEARING, BALL
bull pinion shaft (opt.)
2шт.
4
700521R91
BALL BEARING
BEARING, ball, bull pinion shaft (opt.)
2шт.
4
700523R91
BEARING, BALL
bull pinion shaft (opt.)
2шт.
4
704768R92
BALL BEARING
BEARING, ball, bull pinion shaft (opt.)
2шт.
5
3069954R1
SHAFT
brake L.H. and bull pinion (13 teeth)
1шт.
6
3044002R91
BEARING
roller, differential (Timken) (optional)
2шт.
6
3049255R91
BEARING
roller, differential (S.K.F.) (optional)
2шт.
7
705551R1
LOCK WASHER
PLATE, lock
4шт.
8
NSS
NOT SOLD SEPARAT
CASE, differential (order 3043998R91)
1шт.
9
704215R1
GEAR
bevel, differential (24 teeth)
2шт.
10
704707R1
AXLE DIFFERENTIAL
SHAFT, differential
4шт.
11
3109649R1
GEAR
PINION, differential (13 teeth)
4шт.
17244R1
LOCK PIN,5/16" x 1 1/4", Slotted
PIN, 5/16" x 1 1/4", Slotted
4шт.
12
NSS
NOT SOLD SEPARAT
GEAR, bevel, drive (order 709448R92)
1шт.
3042127R1
BOLT,Hex, 7/16" - 20 x 1 1/8"
retaining, drive bevel gear
12шт.
114607
LOCK, Ext Tooth, 7/16"
12шт.
13
3069955R1
SHAFT
brake, R.H. and bull pinion (13 teeth)
1шт.
14
3071402R11
CAGE
bearing, bull pinion shaft R.H. cpte., w/OIL SEAL 703908R92
1шт.
3071403R1
BOLT,Hex, 7/16" - 14
bull pinion shaft bearing cage roll pin
5шт.
3071405R1
BOLT,Hex, 7/16" - 14 x 1.50"
PIN, roll
1шт.
3071406R1
WASHER
roll pin bolt
1шт.
3070558R1
WASHER
bull pinion shaft bearing cage
1шт.
15
3043998R91
DIFFERENTIAL
CASE, differential cpte., (two halves)
1шт.
NLS
NO LONGER SERVICED
8шт.
