Запчасти Case IH 2544 (M-10) - SEAT, OPERATORS PLATFORM AND MISCELLANEOUS, PACKAGE ASSORTED GASKETS (10) - OPERATORS PLATFORM

395914R93

SET

PACKAGE, chassis overhaul gasket, gear drive tractors, consists of

1шт.

369497R2

GASKET

air intake manifold elbow

1шт.

369860R1

GASKET,0.79mm Thk

front wheel hub cap

2шт.

3960281

GASKET, clutch housing

1шт.

360642R2

GASKET

clutch housing top cover

1шт.

364721R1

GASKET

clutch housing top cover cap

1шт.

360667R3

GASKET

clutch housing rear bottom cover

1шт.

360871R1

GASKET

clutch housing bottom cover

1шт.

370801R1

GASKET

oil strainer opening cover

1шт.

359129R2

GASKET

independent PTO driven

1шт.

394262R1

WASHER

GASKET, flashing warning light

1шт.

23977DB

GASKET

fuel tank filler cap

1шт.

375577R1

GASKET

hyd unit housing

1шт.

376018R1

GASKET

hyd unit housing cover

1шт.

52999D

WASHER

GASKET, hyd pump mtg bolt

1шт.

370892R2

GASKET

pump mtg flange, light

1шт.

370893R2

GASKET

pump mtg flange, heavy

1шт.

388144R2

GASKET

trans pivot shaft support bracket

1шт.

397280R92

PACKAGE

chassis overhaul gasket, hydrostatic drive tractors, consists of

1шт.

369497R2

GASKET

AIR INTAKE manifold elbow gasket

1шт.

369860R1

GASKET,0.79mm Thk

FRONT WHEEL hub cap gasket

2шт.

394262R1

WASHER

FLASHING WARNING light gasket

1шт.

23977DB

GASKET

FUEL TANK filler cap gasket

1шт.

375577R1

GASKET

HYD unit housing gasket

1шт.

376018R1

GASKET

HYD unit housing cover gasket

1шт.

52999D

WASHER

HYD pump mtg bolt gasket

4шт.

388144R2

GASKET

DRAFT control opening cover gasket

1шт.

392007R1

GASKET

TRANS pivot shaft support bracket gasket

1шт.

396027R1

GASKET

IPTO bearing cover gasket

1шт.

396028R1

GASKET

DRIVE HOUSING GASKET

1шт.

396030R2

GASKET

PRESS REG VALVE ACCESS COVER GASKET

1шт.

396034R1

GASKET

DRIVE HOUSING front cover gasket

1шт.

396036R2

GASKET

DRIVE HOUSING bottom cover gasket

1шт.

396040R1

GASKET

DRIVE HOUSING top cover gasket

1шт.

396042R1

GASKET

DRIVE HOUSING side cover gasket

1шт.

396142R1

GASKET

MULTI-VALVE gasket

1шт.

396796R1

GASKET

CAM actuating shaft housing gasket

1шт.

396867R1

GASKET

PUMP mtg flange - light gasket

1шт.

396868R1

GASKET

PUMP mtg flange - heavy gasket

1шт.

396870R1

GASKET

PUMP mtg flange adapter gasket

1шт.

395915R92

KIT

PACKAGE, torque amplifier overhaul gasket, consists of

1шт.

359129R2

GASKET

independent PTO driven gear cover

1шт.

360642R2

GASKET

clutch housing top cover

1шт.

360667R3

GASKET

clutch housing bottom cover rear

1шт.

360871R1

GASKET

clutch comp. bottom cover

1шт.

361187R1

GASKET

clutch hsg top cover cap

1шт.

364721R1

GASKET

clutch hsg top cover cap

1шт.

396028R1

GASKET

clutch housing

1шт.

370695R1

GASKET

pump opening cover

1шт.

370518R1

GASKET

independent PTO drive shaft brg retainer

1шт.

370801R1

GASKET

oil strainer opening cover

1шт.

405945R92

PACKAGE

hydrostatic transmission gasket service, consists of

1шт.

396027R1

GASKET

IPTO brg cover

1шт.

396028R1

GASKET

hyd drive housing

1шт.

396030R2

GASKET

pressure reg valve access cover

1шт.

396034R1

GASKET

drive housing front cover

1шт.

396036R1

GASKET

bottom cover

1шт.

396040R1

GASKET

top cover

1шт.

396042R1

GASKET

side cover

1шт.

396142R1

GASKET

multi-valve

1шт.

396796R1

GASKET

cam actuating shaft housing

1шт.

396870R1

GASKET

pump mtg flange adapter

1шт.

405946R92

SEAL KIT

PACKAGE, hydrostatic transmission seal ring service, consists of

1шт.

297459R1

O-RING,0.116" Thk x 1.048" ID, -914, Cl 6, 90 Duro

7/8 OD tube check valve

1шт.

297459R1

O-RING,0.116" Thk x 1.048" ID, -914, Cl 6, 90 Duro

7/8 OD tube relief valve

2шт.

327085R1

O-RING,0.103" Thk x 1.549" ID, -129, Cl 5, 75 Duro

1-9/16 x 1-3/4 x 3/32 charge pump suction tube

2шт.

343900R1

O-RING,1.051" ID x 0.07" Width

1-1/16 x 1-3/16 x 1/16 charge line plug

1шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

- 5/8 OD charge tube

3шт.

379181R1

O-RING,0.614" ID x 0.07" Width

5/8 x 3/4 x 1/16 regulator valve assy

1шт.

379794R1

O-RING,0.103" Thk x 1.237" ID, -124, Cl 5, 75 Duro

1-1/4 x 1-7/16 x 3/32 charge tube conn. block

1шт.

382782R1

O-RING,0.103" Thk x 2.3" ID, -141, Cl 5, 75 Duro

2-5/16 x 2-1/2 x 3/32 oil filter sealing

1шт.

383024R1

O-RING,0.07" Thk x 0.676" ID, -17, Cl 6, 90 Duro

11/16 x 13/16 x 1/16 charge tube fitting

1шт.

384937R1

O-RING,0.07" Thk x 0.239" ID, -10, Cl 6, 90 Duro

1/4 x 3/8 x 1/16 pressure check pipe

2шт.

384943R1

O-RING,0.739" ID x 0.07" Width

-018, 90 Duro, .739" ID x .070" Thk, Charge Tube

2шт.

384943R1

O-RING,0.739" ID x 0.07" Width

-018, 90 Duro, .739" ID x .070" Thk, Hydraulic Connector

2шт.

388591R1

RING

valve housing seal

1шт.

392385R1

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

-016, 90 Duro, .614" ID x .070" Thk, Center section exhaust

4шт.

610413C1

O-RING,0.139" Thk x 7.73" ID, -265, Cl 5, 75 Duro

transmission change pump

1шт.

252483R1

O-RING,-218, 70 Duro, 1.234" ID x .139" Thk

1-1/4 x 1-1/2 x 1/8

1шт.

368548R1

RING

SEAL RING, oil suction tube

1шт.

396632R1

RING

oil suction tube

1шт.

405172R1

RING

SEAL, rectangular

1шт.

369751R1

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

3/4 OD tube flared tube to relief valve

3шт.

369961R1

O-RING, 2-1/16 x 2-1/4 x 3/32 motor swashplate housing pivot

2шт.

328138R1

O-RING,0.103" Thk x 1.612" ID, -130, Cl 5, 75 Duro

1-5/8 x 1-13/16 x 3/32 pump swashplate housing pivot

2шт.

396122R1

RING

control cylinder anchor shaft sealing

3шт.

396123R1

RING

anchor shaft support fitting

1шт.
