Запчасти Case IH 248 (2-044) - VALVE MECHANISM (02) - ENGINE

1

3055077R6

SUPPORT

BRACKET, models 248, 385, 485 tractor

4шт.

1

3055077R6

SUPPORT

BRACKET, model 258 and 585 tractor

5шт.

179822

BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 5

Models 248, 385, 485 tractor

4шт.

179822

BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 5

Model 258 and 585 tractor

5шт.

179894

BOLT,Hex, 1/2" - 13 x 3 1/4", Gr 5

Models 248, 385, 485 tractor

4шт.

179894

BOLT,Hex, 1/2" - 13 x 3 1/4", Gr 5

Models 258 and 585 tractor

5шт.

3050129R1

LOCK WASHER

WASHER lock, 5/16 inch, models 248, 385, 485 tractor

4шт.

3050129R1

LOCK WASHER

WASHER lock, 5/16 inch, model 258 and 585 tractor

5шт.

2

3055068R1

BUSHING,22mm ID x 30mm OD x 6.8mm L

models 248, 385, 485 tractor

5шт.

2

3055068R1

BUSHING,22mm ID x 30mm OD x 6.8mm L

model 258 and 585 tractor

7шт.

3

3132293R92

ROCKER

ARM ASSEMBLY, with Ref. 5 and 12, models 248, 385, 485 tractor

3шт.

3

3132293R92

ROCKER

ARM ASSEMBLY, with Ref. 5 and 12, model 258 and 585 tractor

4шт.

4

3132019R1

BUSHING,21.15mm ID x 26.09mm OD x 25.4mm L

3шт.

5

3132138R1

NUT

models 248, 385, 485 tractor

6шт.

5

3132138R1

NUT

model 258 and 585 tractor

8шт.

6

3132137R1

ADJUSTMENT SCREW

Models 248, 385, 485 tractor

6шт.

6

3132137R1

ADJUSTMENT SCREW

Model 258 and 585 tractor

8шт.

7

3055669R1

THRUST WASHER

models 248, 385, 485 tractor

6шт.

7

3055669R1

THRUST WASHER

model 258 and 585 tractor

8шт.

8

3055075R2

SPRING

models 248, 385, 485 tractor

3шт.

8

3055075R2

SPRING

model 258 and 585 tractor

4шт.

9

3132292R92

ROCKER

ARM ASSEMBLY, with Ref. 5 and 12, models 248, 385, 485 tractor

3шт.

9

3132292R92

ROCKER

ARM ASSEMBLY, with Ref. 5 and 12, model 258 and 585 tractor

4шт.

10

3132019R1

BUSHING,21.15mm ID x 26.09mm OD x 25.4mm L

3шт.

11

3055069R31

SHAFT

models 248, 385, 485 tractor

1шт.

11

3055069R31

SHAFT

model 385 and 585 tractor

1шт.

12

933565R1

PLUG,M14, Conical

2шт.
