Запчасти Case IH 2300 (4-40) - CHASSIS, PRODUCT GRAPHICS (12) - CHASSIS

1092593R2

PROGRAPH, International 354 L.H.

1шт.

1092594R2

DECAL

PROGRAPH, International 354 R.H.

1шт.

529467R1

PRODUCT GRAPHIC

PROGRAPH, instrument face panel

1шт.

529479R1

PRODUCT GRAPHIC

PROGRAPH, "IH" grille emblem

1шт.

445201

SPRING NUT,5/32", Push-on

5/32 medium

2шт.

1092606R2

PROGRAPH, speed chart - Tachometer (MPH) (354)

1шт.

1092722R1

PRODUCT GRAPHIC

PROGRAPH, speed chart - Tachometer (MPH) (354)

1шт.

533592R1

PRODUCT GRAPHIC

PROGRAPH, governor control

1шт.

1092721R1

PROGRAPH, 2300 series A

2шт.

1080183R1

PRODUCT GRAPHIC

PROGRAPH, generator warning

1шт.

1092745R1

DECAL

PROGRAPH, caution

1шт.

1080064R1

PRODUCT GRAPHIC

PROGRAPH, water trap

1шт.

1080394R1

PRODUCT GRAPHIC

PROGRAPH, patents

1шт.

1092581R1

TAG

inhibitor anti-freeze

1шт.

1092582R1

TAG

caution, radiator is drained

1шт.

120948H3

PRODUCT GRAPHIC

"use diesel fuel oil only"

1шт.

535772R1

PRODUCT GRAPHIC

"diesel"

1шт.

535771R1

PRODUCT GRAPHIC, "gas" (for USA & Canada)

1шт.

112365H3

PRODUCT GRAPHIC, "gasoline" (for USA & Canada)

1шт.

2753972R1

PRODUCT GRAPHIC, "McCormick"

1шт.

1092815R1

DECAL

PRODUCT GRAPHIC, "air cleaner"

1шт.

706274R91

PACKAGE, chassis gasket consisting of the following:

1шт.

703913R3

GASKET,0.79mm Thk

rear axle carrier, packages

2шт.

711197R1

GASKET

rear axle bearing retainer, packages

2шт.

703967R3

GASKET

trans. case cover, rear, packages

1шт.

703969R2

GASKET

trans. case cover, front, packages

1шт.

703971R1

GASKET

cover plate, P.T.O. shaft opening, packages

1шт.

3114906R1

GASKET

cover plate, P.T.O. shifter shaft hole, packages

1шт.

703921R1

GASKET

hub cap, front wheel, packages

2шт.

703987R2

GASKET, trans. countershaft front bearing cage, packages

2шт.

704017R1

GASKET

trans. driving shaft bearing cage, packages

1шт.

711254R1

GASKET

oil seal retainer, trans. driving shaft, packages

1шт.

704613R1

GASKET

exhaust pipe flange, packages

1шт.
